Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe
- Qingdao port
- T/T
You May Like
-
Four Feet CNC Rotary Spindleless Veneer Peeling Machine
-
4-8feet veneer peeling machine/wordworking spindless veneer rotary lathe
-
1400mm CNC No chuck woodworking veneer rotary peeling and cutting lathe
-
China quality plywood veneer core composer / high efficiency veneer splicer
-
HUIXIN brand veneer rotary peeling lathe/plywood veneer making machine in Linyi
-
Veneer dryer/hot pess drying machine for veneer/veneer dry machine
Product Details
| Condition | New | Type | Other, veneer peeling machine | |
| Place of Origin | Shandong, China | Brand Name | HUIXIN | |
| Model Number | WKZ130 | Voltage | 380V | |
| Power(W) | 20.9KW | Dimension(L*W*H) | 3800*2100*1400mm | |
| Weight | 4.5T | Certification | CE, ISO9001 | |
| Warranty | 12 Months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe
Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe
Mainly features:
1. Rotary peeling and cutting are all together.
2. Wood rotary peeling Maximum Diameter is 500mm.
3. The thickness of the veneer, the gap of the knife can be adjusted automatically by itself. So the workers needless
adjust the knife gap by hand.
4. The clipping section could cut the last veneer that is for full size.
5. Feed screw use oil immersion method, improve the service life of the whole machine
6. Compact structure, stable performance, simple operation and high efficiency and other advantages.
Product technical specifications:
Model | WKZ130 |
Log dimension processing (D*L) | 500*1400 mm |
Veneer thickness range | 0.3-4.0mm |
Rotary knife specification (L*W*T) | 1400*130*12.7 mm |
The smallest diameter core | 28mm |
Wire speed of friction roller | 38m/minute |
Diameter of friction roller | 110mm |
Reference output | 20-30m3/day |
Double-roller engine | 1pc*5.5kw |
Single-roller engine | 1pc*5.5kw |
Feeding engine | 1pc*5.5kw |
Rotary clipper engine | 2pcs*2.2kw |
Cutting width | 500-3000mm |
The thickness of clipping veneer | 0.3-4.0mm |
Feeding speed | 0-100m/minute |
Main product dimension (L*W*H) | 3500*2100*1400mm |
Weight | 3.8ton |
Remark: When the product is improved, the appearance and the indexes should be standardized according to the
physical goods.
Photos of Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe
Peeling and cutting are all together
Control box
Cross big friction rollers
Electric wire protect jacket
Veneer cutting section
Big screw for protect jacket
Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe usually packed in nude, 3 sets/40' container or according to your requirements.
Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe
After sales service:
I. Short time abroad service: 3-10 days, one person. The buyer should pay the round-trip air tickets, foods, accommodation and service fee. The services include fixing, debugging, operating, maintaining and workers’ training.
II. The buyer sends workers to seller’s factory for study: 3-10 days, one person. The buyer should pay for the round-trip air tickets. The seller arrange for food and accommodation. The services include fixing, debugging, operating, maintaining.
Ruihao Machinery is a key enterprise as a professional veneer production line machines manufactory in Shandong for 28 years. Our products including: log debarker, wood rotary peeling and cutting machine, veneer dryer, veneer jointing machine, sliding table saw, knife grinder and accessorial for production line. We supply woodworking machinery with high quality and competitive price. Warmly welcome customers home and aboard to cooperate with us in business.
Linyi spindleless veneer rotary cutter machine/veneer peeling machine /log rotary cutting lathe
Payment Terms: By T/T. 30% payment in advance, the balance should be paid before shipment.
Delivery Time: Within 15 working days after advance.
Validity: Within 30 days after the date.
Guaranty for 12 months.
