1. Features:
Polyester filament geotextile is made by polyester textile needle consolidation , product specifications from 80-800g/m2 , it is geosynthetic application in geotechnical and civil engineering , they are arranged in three-dimensional structure of the fiber . In addition to having good mechanical properties, but also has a good aspect to the drainage performance and good elongation properties and high resistance to biological , acid , anti-aging chemical stability . Meanwhile , it also has a wide range of pore size , pore distribution tortuous , excellent permeability and filtration performance .
2. Action:
1, Water conservancy project dams and slope of filtration , channel isolation, impervious ;
2, Highways , railways, airport runways based isolation, filtration , drainage, slopes, retaining walls and pavement reinforcement, drainage ;
3, Port engineering soft ground , beach causeway , harbor piers and breakwaters reinforcement, drainage ;
4, Polyester filament geotextile has been widely used in the field of infrastructure construction , and gradually be applied to a wider range of fields.
3. Technical data:
|
Index |
Remark |
||||||||||
|
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
800 |
|
Deviation of mass per unit area % |
-6 |
-6 |
-6 |
-5 |
-5 |
-5 |
-5 |
-5 |
-4 |
-4 |
-4 |
|
Thickness mm ≥ |
0.8 |
1.2 |
1.6 |
1.9 |
2.2 |
2.5 |
2.8 |
3.1 |
3.4 |
4.2 |
5.5 |
|
Width deviation % |
-0.5 |
|
||||||||||
Break strength kN/m |
4.5 |
7.5 |
10.5 |
12.5 |
15 |
17.5 |
20.5 |
22.5 |
25 |
30 |
40 |
Vertical and horizontal |
Break elongation % |
40~80 |
|||||||||||
CBR bursting strength kN ≥ |
0.8 |
1.4 |
1.8 |
2.2 |
2.6 |
3.0 |
3.5 |
4.0 |
4.7 |
5.5 |
7.0 |
|
Equivalent aperture mm |
0.07~0.2 |
|
||||||||||
Vertical permeability cm/s |
K*(10-4~10-3) |
K=1.0~9.9 |
||||||||||
Tear strength kN≥ |
0.14 |
0.21 |
0.28 |
0.35 |
0.42 |
0.49 |
0.56 |
0.63 |
0.70 |
0.82 |
1.10 |
Vertical and horizontal |
