Help Centerpp Woven Geotextile
Related Products
mainly uses polypropylene(PP),polyethylene(PE) as raw materials. After extruding.It has long term corrosion resistance in the soil and water with different PH;Due to its excellent microbiological degradation resistance. The material is light and soft, so it is convenient to transport and install.
Our product feature high tensile strength and low elongation standards. These have superior capacity for filtration and load distribution, thus reducing rutting and helping inextending the life of paved and unpaved roadways.
1) Weight / Mass: 70g/m2-800g/m2 .
2) Width: Within 6 m (0.5m-6m).
3) Length: 50m-200m/roll (as request).
4) Material: PP and PE
5) Color: Black , green,white , grey, others
6) Manufacturing method: extrude, woven.
7) The famous geotextile manufacturer/factory in China for many years . The equipment is introduced from Germany.
9) This geotextile can be made of polypropylene PPor PE,on needle punch machine.
10) The mass is available from 70g/m² to 800g/m² and the width available from 0.5m-6m, monolayer or multilayer (reinforcement geotextiles), long fiber or short fiber.
11) Color: all kinds of color are available. The annual production ability is 10 million square meters.
12) The fabric can also be heat treated by infrared at customer's requirements. Our geotextile are UV stabilized to give protection against aging under exposure to natural ultra-violet light.
Major functions: Separation, filtration, drainage, reinforcement, protection, and liquid barrier
1) Filtration
The filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2) Separation:
The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
3 )Adding muscle:
The highway, railway, soil-stone dam, breakwater, airport, backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth body stability.
4 )Protection
It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from being washed away.
Technical Parameters
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
800 |
NOTE |
|
BASIS WEIGHT TOLERANCE (%) |
-8 |
-8 |
-8 |
-8 |
-7 |
-7 |
-7 |
-7 |
-6 |
-6 |
-6 |
|
THICKNESS ≥MM |
0.9 |
1.3 |
1.7 |
2.1 |
2.4 |
2.7 |
3.0 |
3.3 |
3.6 |
4.1 |
5.0 |
|
TENSILE STRENGTH AT BREAKING ≥KN/m |
10 |
25 |
30 |
40 |
60 |
80 |
100 |
120 |
140 |
160 |
200 |
|
CBR PLUNGER STRENGTH ≥KN |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.2 |
4.0 |
|
TEARING STRENGTH ≥KN |
0.08 |
0.12 |
0.16 |
0.20 |
0.24 |
0.28 |
0.33 |
0.38 |
0.42 |
0.46 |
0.60 |
|
BREADTH TOLERANCE (%) |
-0.5 |
|||||||||||
ELONGATION AT BREAKING (%) |
15 -100 |
MD&CD |
||||||||||
EOS O90mm |
0.03-0.8 |
|||||||||||
VERTICAL PERMEABILITY (CM/S) |
K×(101~~103) |
K=1.0-9.9 |
||||||||||
