PP Woven Geotextile Used in Road Construction Reinforcement
Product Description
PP Woven Geotextiles are commonly known as Woven Geotextiles. These are made of artificial fibres with various petro-chemical derivatives as their source. Geotextiles are permeable fabrics which, when used in association with soil, have the ability to separate, filter, reinforce, protect, or drain. Our product feature high tensile strength and low elongation standards. These have superior capacity for filtration and load distribution, thus reducing rutting and helping in extending the life of paved and unpaved roadways.
Product Features
- Dimensional stability
- Resistance to the biological and chemical environments
- Low elongation standards
- Resistant to all naturally occurring soil acids and alkalis
- Unaffected by bacteria or fungi
Product Technical Specification
NO. | Item | Index | |||||||
|
| 20-15 | 30-22 | 40-28 | 50-35 | 60-42 | 80-56 | 100-701 | |
1 | Break Strength KN/m≥(LD) | 20 | 30 | 40 | 50 | 60 | 80 | 100 | |
2 | Break Strength KN/m≥(TD) | 15 | 22 | 28 | 35 | 42 | 56 | 70 | |
3 | Break Elongation %≤(LD,TD) | 28 | |||||||
4 | Trapezoidal Tearing Strength KN≥(LD) | 0.3 | 0.45 | 0.5 | 0.6 | 0.75 | 1.0 | 1.2 | |
5 | Burst Strength KN≥ | 1.6 | 2.4 | 3.2 | 4.0 | 4.8 | 6.0 | 7.5 | |
6 | Vertical Permeability Coefficient cm/s | 10-1 _ 10 -3 | |||||||
7 | Sieve Size(O95.)mm | 0.08-0.5 | |||||||
8 | Mass Weight g/m2 | 120 | 160 | 200 | 240 | 280 | 340 | 400 | |
9 | Variation% | ±10 | |||||||
