Specifications
Tri-dimension composite geonet for drainage of landfill1.High tensile and shear strength
2.Excellent drainage function
Tri-dimension composite geonet for drainage of landfill
Tri-dimension composite geonet for drainage of landfill is made of a unique tri-dimension geonet adhibited geotextile on both si
Tri-dimension composite geonet for drainage of landfill has the property of geotextile(filtration function) and geonet(drainage and protection) and provide a function system fitration-drainage-protection .The core of net with its unique tri-dimension structure can bear higher compressiong load in construction and remain the certain thickness,provide good water conductivity.
Typical applications
Landfill drainage;roadbed and road drainage; railway drainage ,tunnel drainage,underground structure drainage, the retaining back wall drainage , gardens and sports grounds drainage.
Features
Excellent drainage function, can bear long time hige press load
High tensile and shear strength
Reduce the rate geotextile embedding into the core of geonet, can protect long time stable water conductivity
Tri-dimension composite geonet for drainage can bear more than kpa compression load
Its anti-compression capacity is much larger than common geonet for drainage.
Physical characteristics
Item |
Units |
Specifications |
|||
Unit weight |
g/ |
750 |
1000 |
1300 |
1600 |
Thickness OV=20kpa |
mm |
5.0 |
6.0 |
7.0 |
7.6 |
Hydraulic conductivity |
m/s |
K×10-4 |
K×10-4 |
K×10-3 |
K×10-3 |
Elongation |
% |
50 |
50 |
50 |
50 |
Tensile strength(core network) |
KN/m |
8 |
10 |
12 |
14 |
Geotextiles |
g/ |
200-200 |
200-200 |
200-200 |
200-200 |
