Specifications
800g geonet and 180g geotextilehomogenous and stable stucture
anti-aging
resisting acid and alkaline
HDPE material
800g geonet and 180g geotextile
800g geonet and 180g geotextile Features:
a. Plastic Geonet enable grainy material and grid combined together to format a stable flat surface which prevent filled material from sinking and distribute the vertical loads multiplayer consolidating can be used in bad geographical condition.
b. Be used in filled soil of road foundation and bank slope, making them further stable and minimizing land use.
c. Being used in enhancing surface of roads through combining grids and surface material can distribute and transfer the loads effectively and prevent roads from crack occurring.
d. Allow baring greatly clashing loads.
e. Allow bear greater alternating loads.
f. Shorten the period of the construction.
g. Allow construct insusceptbly under the bad condition.
h. Prevent road surface from crack commonly caused by surface turning over.
i. Save the quantity of the constructional material.
800g geonet and 180g geotextile Introduction:
Plastic Geonet is suitable for strengthening land,make the net mesh and road material into a whole,can effectively dispaerse loading,prevent land form breaking. HDPE geonet offers special properities,perfect permeability,good flexibility and longtrem durability.Suitable for strengthening land retention walls,strengthen surface from breaking bear much more loading capacity,save the material speed up construction.
800g geonet and 180g geotextile Applications
It is made of high-density polyethylene (HDPE) and the ultravioresistant agent with the property of aging resistance and erosion resistance.
- Using the geo-net on the roadbed of the roadway and railway can distribute the load effectively, improve the loading capacity and the stability of the roadway, and prolong its service life.
- Spreading the geo-net in the dyke protection in the reservoir and the river can protect it from the landslide.
- And with the features of good flexibility and strong erosion resistance, using it in the coast engineering can amortize the concussion and the erosion of the surf
800g geonet and 180g geotextile paremeter Index:
specs index | CE121 | CE131 | CE141 | CE151 | CE153 | CE161 | CE181 | CE191 |
Width (m) | 2.5 | 2.5 | 2.5 | 2.5 | 1.0 | 2.5 | 2.5 | 1.0 |
Mesh size (mm) | (8x6)±2 | (27x27)±3 | (60x60)±5 | (74x74)±5 | (50x50)±5 | (16x16)±1 | (90x90)±5 | (105x105)±5 |
Thickness (mm) | 3.3 | 5.2 | 5.5 | 5.9 | 5.9 | 4.8 | 7.2 | 7.2 |
Ultimate tensile strength (KN/m) | ≥6.0 | ≥5.6 | ≥6.0 | ≥4.8 | ≥4.2 | ≥5.4 | ≥5.7 | ≥5.8 |
Roll length (m) | 40 or as the customers’ request | |||||||
