Specifications
200g pet filter fabricMaterial:PP /PET
Width:1-6m
Weight:100-1200gsm
White/black
200g pet filter fabric
200g pet filter fabric Introduction:
Sometimes called filter fabric, geotextile is made of plastic threads that allow water to pass around them, but not very small particles of soil beneath them. Geotextile separates and contains the base from the underlying soil subgrade. It allows the base to shed water, and prevents the soil around it from working its way into the base.
200g pet filter fabric Feature:
1. High intensity, strong penetration resistance;
2. Resistant to acid and alkaline, corrosion and aging;
3. Excellent permeability and filterability;
4. Low cost, favorable price and convinent construction
200g pet filter fabric Application:
- Filtration of soils in drainage applications by retaining soil particles while allowing for the free flow of water
- Separation and stabilization in road and railway construction
- Prevention of soil movement in erosion control measures
- Cushioning and protection in many containment projects
200g pet filter fabric Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
