PE Gas Pipe Caps and Plugs
Specifications
PE Gas pipe caps and plugs1. Size: 1/8''-30''
2. Color: Yellow, blue, white, black, red, green
PE Gas pipe caps and plugs
Characteristics:
1.Material: Low-Density Polyethylene
2.Color: Refer to Chart
3.it is fit for Standward:GB,ASTM / ASME B36.10M,API,AWWA,BSP,DIN 3A,SMS,GOST ,JIS and so on .
4.Size :1/4“(6mm) to 30.”(762mm)” nominal bore size and complemented with over 120 additional provide tight fit and release pressure build up.
5.Minimum temp. of use: -40°C
6.Fusion temperature: 120°C Elongation: 500 %
It is the material most used in our products as it possesses good chemical characteristics, as well as showing good resistance to knocks, given its elasticity and softness. From a temperature point of view, the recommended range of use is between -40° and +60°
Specification:
| Specification (mm) | SDR11 thickness(mm) | SDR17.6 thickness(mm) |
| 20 | 3 | 2.3 |
| 25 | 3 | 2.3 |
| 32 | 3 | 2.3 |
| 40 | 3.7 | 2.3 |
| 50 | 4.6 | 2.9 |
| 63 | 5.8 | 3.6 |
| 75 | 6.8 | 4.3 |
| 90 | 8.2 | 5.2 |
| 110 | 10 | 6.3 |
| 125 | 11.4 | 7.1 |
| 140 | 12.7 | 8 |
| 160 | 14.6 | 9.1 |
| 180 | 16.4 | 10.3 |
| 200 | 18.2 | 11.4 |
| 225 | 20.5 | 12.8 |
| 250 | 22.7 | 14.2 |
| 280 | 25.4 | 15.9 |
| 315 | 28.6 | 17.9 |
| 355 | 32.3 | 20.2 |
| 400 | 36.3 | 22.8 |
| 450 | 40.9 | 25.6 |
| 500 | 45.4 | 28.4 |
| 560 | 50.8 | 31.9 |
| 630 | 57.2 | 35.8 |
| 710 | 42.1 | |
| 800 | 47.4 |
