PE Landfill Geomembrane 800w Welding Machine

Specifications

             PE Landfill Geomembrane 800w welding machine

PE Landfill Geomembrane 800w welding machine Description:

PE Landfill Geomembrane 800w welding machine is our new developed products, which can weld geomembrane of different thickness and are applicable for welding of all thermal-fused material such as PE, PVC, HDPE, EVA, PP and the like.

PE Landfill Geomembrane 800w welding machine adopts PID automatic thermostatic control with high control accuracy and low temperature fluctuation; speed control adopts PWM automatic voltage and speed regulation circuit, driven by DC servo motor, with great output torque and the operating is stable.

PE Landfill Geomembrane 800w welding machine can maintain a constant speed on the condition of creeping, vertical creeping and variable road load. Also this series of welding machine is stable in performance despite of external temperature and voltage variation.

PE Landfill Geomembrane 800w welding machine Description:

1.Geomembrane welding machine can weld geomembrane of various thickness and are applicable for welding of all thermal-fused material such as LDPE, PVC, HDPE, EVA, PP and the like.

2.The control of this series of welding machine adopts PID automatic thermostatic control with high control accuracy and low temperature fluctuation;

3.Speed control adopts PWM automatic voltage and speed regulation circuit, driven by DC servo motor, with great output torque and the operating is stable.

4.It can maintain a constant speed on the condition of creeping, vertical creeping and variable road load. Also this series of welding machine is stable in performance despite of external temperature and voltage variation.

5.This series of welding machine is excellent in performance and easy for operating, with high welding speed and good work quality. It is extensively used in engineering projects such as expressways, tunnels, reservoirs, waterproof of construction and so on

PE Landfill Geomembrane 800w welding machine Characteristics:
1. Aim at thin materials such as PVC and geotextile, light and rapid.
2. Aim at the thickest HDPE geomembrane, heavy load and high torque.
3. Simple operation, long working time, good effect even use thin materials.
4. No need for adjust the machine again for welding materials with various thicknesses (such as 40, 60, 80mil)
5. Adjustable rod for controlling membrane fold and bottom pad, fit for indoor high speed operation.
6. 9.8m/min
7. Simple operation, it only needs to press button for speed and temperature control.



PE Landfill Geomembrane 800w welding machine Technical Information:
Type: VM-20, VM-20FK, VM-993
Weight: only for 12.25kg (27lbs)
Shipping Weight: 20kg(45lbs)
Voltage: 220VAC,50/60HZ
Power: 1800W
Current: 7.5A @ 220W
Temperature Range: surrounding temperature 425°C(-850°F)
Welding Width: 31.75—80mm(1.25”--3”)tank welding or welding without tank
Speed: 0-12.7m/min (0-42inch/min)
Materials Range: 0.3—3mm (12--120mil ) PE, PP, PVC and other geomembrane
4--50OZ./sq.yd. nonwoven geotextile

PE Landfill Geomembrane 800w welding machine Additional Devices:
1.FK-100 is indoor operation pad and rod for folding control for adjustable membranes.
2. RF-100 is the rack for loose ground or sand.
3. Operation rod for hoist and brake device
4.Front wide (pipe) running roller or single roller.
5. Increase intensity for wide welding track for roller with 7.7cm width.
