Unixial Geogrid HDPE/PP

Specifications

Unixial Geogrid HDPE/PP
material:HDPE,PP
width:<3m
length:10-100m (based on customer's requirements)

                                           Unixial Geogrid HDPE/PP

Unixial Geogrid HDPE/PP represent a rapidly growing segment within the geosynthetics area.rather than being a woven,nonwoven or knit textile fabric,geogrids are plastics formed into a very open,gridlike configuration.geogrid are either stretched in one or teo directions for improved physical properties or made on weaving machinery by unique methods.
 Unixial Geogrid HDPE/PP  Properties
1.high tensile force
2.nice flexibility
3.anti-aging
4.resisting acid and alkaline
Applications of Unixial Geogrid HDPE/PP

Reinforced handle a variety of soft,enhanced to improve the roaded subgrade bearing capacity and long-term stress state retaining walls,strrp slopes,embankments,bride abutment reinforcement,improve project quality,to extend the life of the project.



 Unixial Geogrid HDPE/PP Performance Parameters



Item	TGDG50	TGDG65	TGDG80	TGDG100	TGDG120	TGDG135	TGDG160
Raw Material	HDPE	HDPE	HDPE	HDPE	HDPE	HDPE	HDPE
Carbon Black Content  (%)≥	2	2	2	2	2	2	2
Vertical Tensile Strength  (KN/m) ≥	50	65	80	100	120	135	160
Tensile Strength at 2% elongation  (KN/m) ≥	14	18	23	29	35	39	47
Tensile Strength at 5% elongation  (KN/m) ≥	27	35	44	55	65	74	85
Yield elongation (%≤)	12	12	12	12	12	12	12
Creep limit strength (KN/m)	21	25.5	31	39	46	51	60
Final product's strength (m)	50	50	50	50	50	50	50
Width (m)	1-3
