200g to 800g Waterproof Compound Geomembrane
- 60 Square Meter / Square Meters per Month
- Qingdao
- T/T
- 2mm HDPE Geomembrane for Fish Pond Waterproof membrane Dam Pond Liner Landfill project geomembranes
- 1.5mm HDPE Geomembrane for Fish Pond Waterproof membrane Dam Pond Liner Landfill project geomembranes
- 1mm HDPE Geomembrane for Fish Pond Waterproof membrane Dam Pond Liner Landfill project geomembranes
- 0.75mm HDPE Geomembrane for Fish Pond Waterproof membrane Dam Pond Liner Landfill project geomembranes
- 0.5mm HDPE Geomembrane for Fish Pond Waterproof membrane Dam Pond Liner Landfill project geomembranes
- Geomembrane 0.50mm 0.75mm 1.0mm 1.5mm 2.0mm Fish Farm Pond Liner Dam Liner HDPE Geomembrane
Product Details
Place of Origin: | Shandong, China | Brand Name: | Starring | Material: | HDPE, LDPE, LLDPE |
Product Description
Specifications
200g to 800g Waterproof Compound Geomembrane1.Excellent drainage,separation,filtration
2.Creep,corrosion abrasion resistance
200g to 800g Waterproof Compound Geomembrane
Compound geomembrane with different type
Name | compound geomembrane |
Description | using non-woven geotextile as the base and PE/PV as the membrane material |
Feature | 1. high strength and excellent tenacity |
2. anti-aging,acid and alkali | |
3. creep , corrosion and abrasion resistance | |
4. safe and easy for construction | |
Type | 1. one piece of geotextile and one piece of membrane |
2. two pieces of geotextile and one piece of membrane | |
3. one piece of geotextile and two pieces of geomembrane | |
4. muti-layers and so on | |
Range | used in dam, traffic tunnel, road, airport, drainage, housing and many |
other filds for waterproof protection ,reinforcement and so on . |
Technical Specification of Compound Geomembrane
Item | Value | ||||||||
Nominal Breaking Strength(KN/M)
| 5 | 7.5 | 10 | 12 | 14 | 16 | 18 | 20 | |
1 | Breaking Strength(MD/CD)/(KN/m)
| 5.0 | 7.5 | 10 | 12 | 14 | 16 | 18 | 20 |
2 | Breaking Elongation(MD/CD)/1%
| 30-100 | |||||||
3 | CBR Mullen Burst Strength≥
| 1.1 | 1.5 | 1.9 | 2.2 | 2.5 | 2.8 | 3.0 | 3.2 |
4
| Tear Strength(MD/CD)/(KN/m)≥
| 0.15 | 0.25 | 0.32 | 0.40 | 0.48 | 0.56 | 0.62 | 0.70 |
5 | Hydraulic Pressure /MPA
| As table 2 | |||||||
6 | Peel Strength/(N/cm)
| 6 | |||||||
7 | Vertical Permeability Coefficient/(CM/S) |
According to request | |||||||
8 | Width Variation/% | -1.0 |
Table2
Thickness of membrane | 0.2 | 0.3 | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 |
Note |
One textile one membrane mm | 0.4 | 0.5 | 0.6 | 0.8 | 1.0 | 1.2 | 1.4 | |
Two textile one membrane mm | 0.5 | 0.6 | 0.8 | 10. | 1.2 | 1.4 | 1.6 |
Note:The above table is referring to GB/T17639-2008,GB/T17642-2008 Standard.
(Special sizes are available at customer’s request)
