High Quality Composite Geomembrane-HDPE

Specifications

 High Quality Composite Geomembrane-HDPE


Product Description

  Compound geomembrane is a non-woven complex geomembrane, using non woven geotextile as the base,and polyethylene (PE),PVC membrane, etc. as membrane materials. The product is formed after the processes of calendering, spreading and rolling.

Products Features

Excellent physical and mechanical performance

High tearing resistance

Good deformation adaptability

High puncture resistance

High aging resistance

High UV resistance

Anti-acid and alkali

Excellent low and high temperature resistance

Innocuous ,long life span

Product Specification

1.One piece of geotextile and one piece of membrane:

Weight of base geotextile:100-1000g/m²;Thickness of geomembrane :0.1-1.5mm

2.Two pieces of geotextile and one piece of membrane:

Weight of base geotextile:80-600g/m²;Thickness of geomembrane: 0.2-1.5mm

3.One piece of geotextile and two pieces of geomembrane:

Weight of base geotextile :100-1000g/m²;Thickness of geomembrane :0.1-0.8mm

4.Multi-layers:

Weight of base geotextile :100-1000g/m²; Thickness of geomembrane :0.1-0.8mm

Packing Specification

Width:2-6m  Length:50-100m (customized)

Application range

 Widely used in dam ,traffic tunnel,road,airport ,drainage, housing,environmental protection and many other fields for waterproof protection,reinforcement,etc.

 Technical Parameters of Compound Geomembrane

                                                                        GB/T17642-2008
