A TechoTubes are large Geotube structures fabricated from high strength woven geotextile with soil-in-fills. Geotextile tube is formed in situ by the hydraulic pumping of local soil into the prefabricated geotextile tube. This leads to a flexible, monolithic, continuous structure that is highly resistant to water currents. Sand is widely used as the soil in-fill material because of its low compressibility but other hydraulically pumped soil types can be used. Geotextile tubes are normally characterized in terms of theoretical diameter.
Physical properties | Test Method | Unit | Value |
Unit weight | ASTM D 5261 | g/m2 | 510(+-5%) |
Color |
|
| white |
Width |
| M | 3.45-3.75 |
Mechanicalproperties |
|
|
|
Tensile Strength MD | ASTM D 4595 | KN/M >= | 75 |
Tensile Strength CD | ASTM D 4595 | KN/M >= | 100 |
Enlongation at break MD | ASTM D 4595 | % <= | 28 |
Enlongation at break CD | ASTM D 4595 | % <= | 25 |
CBR puncture strength | ASTM D 6241 | KN/M >= | 9 |
Hydraulic properties |
|
|
|
Pore opening size 090(095) | ASTM D 4751 | mm | 0.3-0.5 |
Permeability | ASTM D 4491 |
|
|
UV resistance |
| cm/s | (3-5)*10-2 |
Other colors are availible | 70% Strength retained after 500 hours |
|
|
1. High strength, low deformation geotube geotube
2. Durability: steady property, not easy to resolved, air slaked and can keep the original property long term
3. Anti-erosion: anti-acid, anti-alkali, resists insects and mould geotube
4. Permeability: could control the sieve size to retain certain permeability geotube
5.Effective high volume containment
6.Efficient dewatering and volume reduction
7.Cost effective
8.No special equipment required
otube
A Company You Can Trust:
Located in Ling County, Dezhou Shandong China. established in June 1987, now we are the largest production base and professional manufacturer of geosynthetics products. We have more than 25 years of experience in this field.
Our aim is to help customers realize their goals. We are making great efforts to achieve this win-win situation and sincerely welcome you come and visit our fac. And if we are lucky we can cooperation with each other.For any question, or any further support, pls don't hesitate to contact us.Your early feedback and comments will be highly appreciated.
China supplier civil building material automatic roof shingle Colorful asphalt shingles
1. How about the delivery time?
Lead time since receipt of 30% T/T deposit payment: 3 weeks.
2. What kind of payments does we support?
T/T, L/C, Cash are accepted.
3. What's are the MOQ?
We can according to your condition to set the MOQ.
And we can provide you samples for quality inspection.
4. How to deal with the sample charge?
Accordeing to our company policy, the samples are free, we only charge the freight fee.
And we will return the freight fee If you set the order .
5. Can you produce the product according to customers' requirements ?
Sure, we are professional manufacturer, OEM and ODM are both welcome.
6. Can you tell me your main customers?
That's our customers' privacy, we should protect their information.
At the same time, please rest assured that your information is also safe here.
