Stone Processing Machine For Automatic Edge Polishing Machine
The main body structure of automatic edge polishing machine is designed rationally and has high hardness, which effectively ensures the durability and firmness, and impact and vibration resistance , especially the dynamic head can provide enormous torque, thus promote the operation efficiency.
Automatic edge polishing machine adopts advanced PLC automatic-control profile modeling system, frequency conversion technology, oil-immersion type sealed guide rail, fully automatic control, and computer automatic tracking.
| Unit | ZDMB-1 | |
| Useful working length | mm | 3200 |
| Useful working thickness | mm | 20-50 |
| Width of working table | mm | 1000 |
| Number of spindles | 1 | |
| Forward speed | m/mim | 0-60 |
| Diamond and abrasive wheels diameter | mm | 130 |
| Power of spindles | HP/kW | 4/3 |
| Max power used | HP/kW | 5/3.75 |
| Double speed wheel rotation | 1400/2800 | |
| Compressed air at 7 bar | L/min | 100 |
| Necessary water at 2 bar | L/min | 30 |
| Machine size | mm | 4700×1700×2200 |
| Machine weight | kg | 2300 |
This Automatic Edge Polishing Machine is dexterous and original design, well face connects after processing line, high manufacture efficiency. The blade makes latitudinal automatic leftward or rightward movements along with the patter rail and electro-optic probe to implement cutting. The whole stone polisher is novel in design, elegant in shape, compact in structure, stable in performance and low failure rate.
The automatic edge polishing machine is particularly applicable for processing all kinds of different sizes and thickness of stone edges and special shapes, including curve and beeline shape and profile, edge on granite or marble and every kind of natural stone.
Guarantee for one year,24-hour technical support by email or calling User-friendly English manual and Video CD for machine using and maintaining.
