US$ 295 - 325 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Bestsun roofing system
Model Number:
BPS300W roofing system
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Bestsun roofing system
Model Number BPS300W roofing system
Specification Normal
Application Home
Output Voltage (V) roofing system 110V
Load Power (W) roofing system 300W
Solar Power (W) roofing system 300W
Work Time (h) roofing system 12H

roofing system

1. All solar Systems have LCD digital display which allows you to see the system working, (eg) Charge data,System voltage, Daily power consumption and temperature.
2. All type of BPS  solar system both has AC and DC output.  Also have AC back up charger function.
3. All  solar system have automatic switch , If mains power goes off the system will switch automatically over to battery power,When mains power resumes the system will switch back automatically. The battery's will resume recharging automatically.
4. All  solar inverters are Pure Sine Wave inverters. This allows the use of Air Conditioners and refrigerators without any problem.
5.Each component has a single chip detector. Assembled by the IPM or IGBT of Mitsubishi ,This protects the  solar system from Overloads, Low Voltage and Under Voltage (alarm) Over Heating, Short circuit, Reverse Polarity.
6. BPS solar system can be updated very easily.Just by adding extra components your system will increase power capacity.
7. Solar system Simple to install , just follow installation instructions.
8. Our solar System offers Cutting Edge Technology, State of the Art Quality with Greater Functionality than our competitors, at Competitive prices.

Technical data:
Capacity300VA
Output wavePure sine wave
Output current1.09A(220V) / 2.18A(110V))
PREcision of output voltage±3%
Precision of output frequency±0.1%
False output wave of ACless than 3%
Power factor0.8
Overload ability120%,30 seconds
Invert efficiencyMore than 85%
Output voltageAC110/220V
Output frequency50HZ/60HZ
Maximum output power of Solar Module200W
Maximum output voltage of solar module35V
Maximum output current of solar module5.7A
Battery capacity24V100AH
Best output power everyday644WH
Reference: Max Power Supply Capacity Reference
Name of LoadModelPowerQuantityWorking Time per Day (H)Continued Working Days
Color TV 21 inch65W16.53 continued overcast and raining days
Satellite TV Receivers 25W16.5
Energy-saving lamp 11W23.5

roofing system

roofing system 300W
