3kw Off-grid Hybrid Wind Solar Charge Controller With LCD Dispaly

3kw Hybrid Charge Wind Solar Controller


Modular design, simple, powerful and stable
PWM charging with voltage and current regulation,users can set the brake speed precisely
High quality components to guarantee normal operation under -30°C
Multiple protections including TVS lightening
protection, over-charge, over-discharge, short circuit and anti-reverse protections
LCD displays for system operation status and parameters
Optional low-speed turbine charging function
Optional computer communication function: additional
RS232, RS485 interfaces and monitoring software

Rated wind turbine power: 3000w
Rated solar power: 1000w
System voltage: 48v, 96/120/220/240v optional
Max. wind turbine input current: 10A
Max. wind turbine input power: 5000w
Unload voltage/current: 252v/0-25A adjustable
Max. PV charge current: 10A
Work temp. and humidity: -20-+55°C/35-85%RH

Weight: 20kg
