Help CenterStanding Metal Balls With Base 6mm-1000mm
Related Products
-
Art Sculpture Carbon Steel Fire Pits ,steel Sphere Fire Pits for Outdoor DecorationUS$ 800 - 800MOQ: 1 Piece -
Decorative Outdoor Iron Mild Steel Fire Pits,china Carbon Steel Fire Ball/sculptureUS$ 800 - 800MOQ: 1 Piece
-
Mirror Finishing 600mm Water Feature Sphere/ball Fountain BallUS$ 0.1 - 1,000MOQ: 1 Piece
-
Big Size Stainless Steel BallUS$ 0.00001 - 1MOQ: 20 Pieces
-
Gazing Balls Indoor DecorUS$ 0.1 - 100MOQ: 1 Piece
Specifications
all size good quality standing metal balls with base 6mm-1000mmPhysical capability of stainless steel balls | ||||
|
CAPABILTY MODEL |
201 |
302 |
304 |
316 |
Tensile strength |
100,000 - 180,000 psi |
100,000-180,000 psi |
100,000 - 180,000 psi |
90,000 psi |
Yield strength |
50,000 - 150,000 psi |
50,000-150,000 psi |
50,000 - 150,000 psi |
45,000 psi |
Tensibility |
55-60% |
55-60% |
55 - 60% |
35% |
Modulus of Elasticity |
29,000,000 psi |
29,000,000 psi |
29,000,000 psi |
28,000,000 psi |
Density |
280lbs/cubic inch |
286lbs/cubic inch |
286 lbs/cubic inch |
290lbs/cubic inch |
Chymic component of 304 stainless steel balls | ||||
|
CS MODEL |
201 |
302 |
304 |
316 |
C |
0.15% max |
0.15% max |
0.08% max |
0.08% max |
Si |
1.00% max |
1.00% max |
1.00% max |
1.00% max |
Mn |
5.50-7.50% |
2.00% max |
2.00% max |
2.00% max |
P |
0.045% max |
0.045% max |
0.045% max |
0.045% max |
S |
0.03% max |
0.03% max |
0.030% max |
0.03% max |
Cr |
16.00-18.00% |
17.00-19.00% |
17.00- 19.00% |
16.00-18.00% |
Molybdenum |
----- |
----- |
----- |
2.00-3.00% |
Ni |
3.50-5.50% |
8.00-10.00% |
8.00 --10.00% |
10.00-14.00% |
N |
----- |
----- |
----- |
0.10% max |
Nitrogen |
0.25% max |
----- |
----- |
----- |
Grade 304 is the standard "18/8" stainless; it is the most versatile and most widely used stainless steel, available in a wider range of products, forms and finishes than any other. It has excellent forming and welding characteristics. The balanced austenitic structure of Grade 304 enables it to be severely deep drawn without intermediate annealing, which has made this grade dominant in the manufacture of drawn stainless parts such as sinks, hollow-ware and saucepans. For these applications it is common to use special "304DDQ" (Deep Drawing Quality) variants. Grade 304 is readily brake or roll formed into a variety of components for applications in the industrial, architectural, and transportation fields. Grade 304 also has outstanding welding characteristics. Post-weld annealing is not required when welding thin sections.
Corrosion Resistance
Excellent in a wide range of atmospheric environments and many corrosive media. Subject to pitting and crevice corrosion in warm chloride environments, and to stress corrosion cracking above about 60°C. Considered resistant to potable water with up to about 200mg/L chlorides at ambient temperatures, reducing to about 150mg/L at 60°C.
Heat Resistance
Good oxidation resistance in intermittent service to 870°C and in continuous service to 925°C. Continuous use of 304 in the 425-860°C range is not recommended if subsequent aqueous corrosion resistance is important. Grade 304L is more resistant to carbide precipitation and can be heated into the above temperature range.
Heat Treatment
Solution Treatment (Annealing) - Heat to 1010-1120°C and cool rapidly. These grades cannot be hardened by thermal treatment.
