15'' Touch Screen High Resolution Portable Ultrasound Scanner Ultrasonic Diagnostic Device With Multi-frequency Probes

Display Mode:

B,M,2B,B/M,4B

Gray Sacle:

256

Display:

15" Touch Screen

Transducer Frequency:

2-11MHz

Scanning Depth:

190mm

Cine-loop:

334 Frame Cine Loop Memory

USB Ports:

2

Zoom:

Pan Zoom

Measurement & Calculations:

Distance, Angle, Area, Volume, Trace Length, Distance Ratio, Time, Slope, HR

Software Packages:

Abdomen, OB, Gynecology, Small Part

Transducer Connector:

2

Peripheral Ports:

Video,2 USB Ports,1 Networking Port,1 Power Inlet,1 Equipotential Terminal

Dimensions(main Unit):

358mm(W)*366mm (L)*65mm (H)

Net Weight:

3kgs

Packing Dimensions:

420mm(W)*430mm(L)*150mm(H)

Gross Weight:

6kgs

Warranty:

12 Months

Display mode

B,M,2B,B/M,4B

Gray sacle

256

Display

15" Touch Screen

Transducer frequency

2-11MHz

Digital technology

Wide-angle imaging

Panoramic focusing technology

Rolling M technology

Scanning depth

190mm

Pre-processing

Cloud processing technology

8-segment TGC

Gain(B&W)

Dynamic range

Persisitence

M Soften

Noise suppression

Post-processing

Image enhancement

Gray Map

Colorize Map

Tissue Specific Imaging

Left/right reverse

Up/down reverse

Cine-loop

334 frame cine loop memory

USB ports

2

Zoom

Pan zoom

THI

Tissue Harmonic Imaging

Qopt

Optimize

DICOM 3.0

DICOM 3.0

B mode

Distance, angle, area, volume, trace length, distance ratio

M mode

Distance, time, slope, HR

Software packages

Abdomen, OB, gynecology, small Part

Transducer connector

2 active transducer connector ports

Peripheral ports

Video,2 USB ports,1 networking   port,1 power inlet,1 equipotential terminal

Power supply

AC110V~220V, 50/60Hz

Dimensions(main unit)

358mm(W)*366mm (L)*65mm (H)

Packing dimensions

420mm(W)*430mm(L)*150mm(H)

Net weight

Approximately 3.0kg

Gross weight

Approximately 6.0kg
