Product Name:Double Layer PP Rope
Material:polyproplene
Products Description: Double Layer PP Rope is the most durable ropes of the common material ropes in marine and industrial area. It has high strength, both wet and dry, good resistance against external abrasion and does not lose strength rapidly due to cyclic handling.
Application: mooring line, anchor line, towing rope
Length per coil: 220m
Spliced strength: ±10% lower
Weight and length tolerance: ±5%
MBL: ISO 2307 strandard
Other sizes can be customized
Parameter Table
| dia | PA multi | PA yarn | PP multi | PP mono | Polyester | PES/PP mixed | |||||||
| mm | ktex | kn | ktex | kn | ktex | kn | ktex | kn | ktex | kn | ktex | kn | |
| 4 | 10 | 3.7 | 10 | 2.6 | 6.3 | 2.3 | 6 | 2.1 | 12 | 2.9 | 7 | 2.8 | |
| 6 | 22 | 7.9 | 22 | 6 | 18 | 6.5 | 17 | 5.9 | 27 | 5.6 | 17.5 | 6.8 | |
| 8 | 40 | 13.8 | 40 | 10.9 | 32 | 11.4 | 30 | 10.4 | 48 | 10 | 31 | 11.9 | |
| 10 | 62 | 21.2 | 62 | 15.7 | 47 | 16.8 | 45 | 15.3 | 76 | 15.6 | 48.5 | 18.2 | |
| 12 | 89 | 30.1 | 89 | 24.1 | 68 | 23.9 | 65 | 21.7 | 110 | 22.3 | 69.9 | 25.7 | |
| 14 | 121 | 40 | 121 | 33 | 95 | 32.9 | 90 | 29.9 | 148 | 31.2 | 95.1 | 34.7 | |
| 16 | 158 | 51.9 | 158 | 42.5 | 121 | 40.7 | 115 | 37 | 195 | 39.8 | 124 | 44.8 | |
| 18 | 200 | 64.3 | 200 | 53.9 | 155 | 51.9 | 148 | 47.2 | 245 | 49.8 | 157 | 56.1 | |
| 20 | 247 | 79.2 | 247 | 66.7 | 189 | 62.6 | 180 | 56.9 | 303 | 62.3 | 194 | 68.7 | |
| 22 | 299 | 94 | 299 | 80.4 | 231 | 75 | 220 | 68.2 | 367 | 74.7 | 235 | 82.1 | |
| 24 | 355 | 112 | 355 | 96.3 | 273 | 87.7 | 260 | 79.7 | 437 | 89.6 | 279 | 96.3 | |
| 26 | 417 | 129 | 417 | 111.5 | 320 | 101 | 305 | 92.2 | 512 | 105 | 328 | 113 | |
| 28 | 484 | 149 | 484 | 127 | 373 | 115 | 355 | 105 | 594 | 120 | 380 | 130 | |
| 30 | 555 | 169 | 555 | 143 | 425 | 132 | 405 | 120 | 682 | 134 | 437 | 148 | |
| 32 | 632 | 192 | 632 | 161 | 483 | 146 | 460 | 132 | 778 | 154 | 497 | 167 | |
| 36 | 800 | 240 | 800 | 200 | 614 | 182 | 585 | 166 | 982 | 190 | 629 | 210 | |
| 40 | 987 | 294 | 987 | 241 | 756 | 221 | 720 | 201 | 1215 | 235 | 776 | 257 | |
| 44 | 1190 | 351 | 1190 | 289 | 924 | 266 | 880 | 242 | 1468 | 275 | 939 | 308 | |
| 48 | 1420 | 412 | 1420 | 338 | 1092 | 308 | 1042 | 280 | 1750 | 329 | 1110 | 364 | |
| 52 | 1670 | 479 | 1670 | 393 | 1281 | 357 | 1220 | 325 | 2050 | 384 | 1320 | 424 | |
| 56 | 1930 | 550 | 1930 | 450 | 1491 | 408 | 1420 | 371 | 2380 | 439 | 1520 | 489 | |
| 60 | 2176 | 630 | 2176 | 520 | 1720 | 460 | 1750 | 430 | 2700 | 510 | 1990 | 600 | |
| 64 | 2475 | 710 | 2475 | 780 | 2000 | 530 | 1986 | 480 | 3100 | 590 | 2270 | 640 | |
| 72 | 3133 | 880 | 3133 | 720 | 2500 | 660 | 2527 | 610 | 3818 | 742 | 2870 | 800 | |
| 80 | 3868 | 1100 | 3868 | 890 | 3100 | 817 | 3086 | 740 | 4636 | 910 | 3540 | 980 | |
| 88 | 4680 | 1300 | 4680 | 1100 | 3810 | 980 | 3748 | 890 | 5636 | 1090 | 4280 | 1170 | |
