Product Name :XCMAX rope
Material :UHMWPE
Color : As you Like
Products Description
UHMWPE ropes are more abrasion resistant than high carbon steel, are resistant to UV light and they float!
UHMWPE Ropes are also have much less stretch than nylon or Dacron lines.UHMWPE Ropes are great for most sailboat lines, mooring lines, tow and winch lines.
Length per coil: 220mSpliced strength: ±10% lower
Weight and length tolerance: ±5%
MBL: ISO 2307 standard
Other sizes can be customized
Parameter Table:
| | |||||
| dia | cir | weight | mbl | ||
| mm | inch | kgs/100m | lbs/100ft | ton | kn |
| 6 | 3/4 | 2.3 | 1.5 | 3.16 | 31.6 |
| 8 | 1 | 4 | 2.5 | 5.18 | 51.8 |
| 10 | 1–1/4 | 6.1 | 37 | 7.94 | 79.4 |
| 12 | 1–1/2 | 8.7 | 5.3 | 13 | 130 |
| 14 | 1–3/4 | 11.7 | 7.1 | 15 | 150 |
| 16 | 2 | 15.1 | 9.2 | 19.6 | 196 |
| 18 | 2–1/4 | 19 | 11.6 | 24.3 | 247 |
| 20 | 2–1/2 | 23.2 | 14.3 | 30.2 | 302 |
| 22 | 2–3/4 | 28.1 | 17.2 | 35.9 | 359 |
| 24 | 3 | 33.1 | 20.4 | 42.1 | 421 |
| 26 | 3–1/4 | 38.4 | 24 | 48.3 | 483 |
| 28 | 3–1/2 | 44.5 | 27.8 | 55.1 | 551 |
| 30 | 3–3/4 | 50.6 | 31.8 | 61.9 | 619 |
| 32 | 4 | 57.5 | 36.2 | 70.3 | 703 |
| 34 | 4–1/4 | 64.8 | 40.8 | 77.8 | 778 |
| 36 | 4–1/2 | 72 | 45.8 | 84.2 | 842 |
| 38 | 4–3/4 | 79.8 | 51 | 93.6 | 936 |
| 40 | 5 | 88.1 | 56.5 | 102 | 1020 |
| 42 | 5–1/4 | 95.5 | 62.2 | 111 | 1090 |
| 44 | 5–1/2 | 106 | 68.3 | 118 | 1180 |
| 46 | 5–5/8 | 114.6 | 74.6 | 130 | 1280 |
| 48 | 6 | 125 | 81.3 | 138 | 1380 |
| 50 | 6–1/4 | 135.4 | 88 | 1746 | 1485 |
| 52 | 6–1/2 | 146 | 95.3 | 159 | 1590 |
| 56 | 7 | 169 | 111 | 183 | 1830 |
| 60 | 7–1/2 | 193 | 127 | 205 | 2050 |
| 64 | 8 | 220 | 144 | 230 | 2300 |
| 68 | 8–1/2 | 248 | 163 | 256 | 2560 |
| 72 | 9 | 278 | 182 | 285 | 2850 |
| 76 | 9–3/8 | 309 | 204 | 315 | 3214 |
| 80 | 10 | 343 | 225 | 355 | 3480 |
| 88 | 11 | 417 | 272 | 429 | 4210 |
| 96 | 12 | 497 | 324 | 510 | 5000 |
