Dampcourse
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | GW | |
| Model Number | DPC |
Product Description
Specifications
damp proof courses:Waterproof, dampproof, ageing-resistant, leakproof 2) No flowing at highest temperature and no crack at
1. Introduction:
Damp proofing in construction is a type of waterproofing applied to building foundation walls to prevent moisture from passing through the walls into interior spaces.
2.Usage:
A damp-proof course (often abbreviated to DPC) is a horizontal barrier in a wall designed to resist moisture rising through the structure by capillary action - a phenomenon known as rising damp.
3.DPC:
In simpler words, DPC is used to stop dampness in buildings. In theory, due to capillary movement of water, water rises from earth to the building. Passing through foundation it rises higher to reach walls. Reaching water to walls may damage them by creating cracks, breaking cement-paint bonds and creating dark-spots on wall etc. So, to avoid water from reaching to walls, we lay DPC layer at plinth level (the joint level of walls and foundations). DPC layer is usually laid below all the walls unaffected from the issue that the respective wall is a load bearing wall or a partition wall.
4.Specification
Thickness: 450-1200um
Size/roll: Width: 5-150m; Length: 30-100m
A damp proof course ( DPC ) is a physical barrier inserted into the fabric of a building to stop water passing from one place to another. This can be on a horizontal plane, stopping water rising up from the ground by being sucked up by the dry masonry above, or vertically to stop water passing from the outside of a building, though the masonry, to the inside. DPC's have taken many forms through the ages and one of the earliest forms was to use a layer of slate in the construction. Slate is still used but the less expensive plastic version ( below right ) is now more widely used
1) Waterproof, dampproof, ageing-resistant, leakproof
2) No flowing at highest temperature and no crack at
Technical Specification of DPC
Water Vapour Permeability | 0.28 gm2 day-1 | BS3177 |
Water Vapour Transmission | 733 MNsg-1 |
|
Water Absorption | 0.22% | BS2782 : 430A |
Resistance to Leakage at Joints | PASS | MOAT 27 : 5.2.1 |
Tensile Strength of Joint | UNAGED : 300 N | MOAT 27 : 5.2.2/3/4 |
Cold Flex Temperature | −60°C | BS2782 : 320A |
Tensile Strength | L : 12.9 Nmm-2 | BS2782 : 320A |
Elongation at Break | L : 415% | BS2782 : 320A |
Tear Strength | L : 122 Nmm-1 | BBA Method |
Low Temperature Flexibility | L : <−25 | MOAT 27 : 5.4.2 |
Dimensional Stability | L : −2.0% | MOAT 27 : 5.1.6 |
Mortar Adhesion Test | PASS | Cream Method |
POLYTHEN EMBOSSED BELT AND
LDPE FILM /POLYTHENE FILM /SHEET CONSTRUCTION FILM
HAS THE FOLLOWING INFORMATION
THE DPC AND DPM POLYTHENE PRODUCTS ,
DPC COLOR BLACK
THICKNESS 450UM--750UM _1200GAUGE---2000GAUGE
LENGTH :30M-100M
WIDTH:50MM---1500MM
