composite earthwork film , composite geomembrane, composite earthwork film ,.anti-aging,waterproofing, corrosion resistance, hi
Composite geomembrane, a waterproof material, compound with geotechnological fabric and geomembrane. It divides into one cloth one membrane and two cloth first membrane, width 4-6m, weight range is 200-1500G/M2. The geomembrane is against drawing, tearing resistance, and high CBR plunger strength, can meet the need of civil engineering such as water conservancy, municipal administration, building, traffic, subway, tunnel etc. Because of selecting high polymer materials for use and adding the aging-resistant materials in the production technology, it can use in the unconventional temperature environment.
Specification: HDPE, LDPE, LLDPE, Thickness: 0.2mm-2.50mm
By processing methods: Smooth surface, single rough surface, spot surface, rugged surface
Width: 1m-8m for thickness < 1.0mm, 1m-8m for thickness of 1.0mm-2.5mm
A typical 20GP can house 5.95m, 40GP can house more than 6m
Length: 50m-100m, or as required by customer
Color: Black, White, Blue, Green, or different colors on both sides.
Production Ability: 30 tons/day
Production Process: Geomembrane, also known as water-proof plate, is made from polymer materials like polyethylene, through blow molding.
Weight,g/m2 |
400 |
500 |
600 |
700 |
800 |
900 |
1000 |
Remark |
Thickness(mm) |
0.25~0.35 |
0.3~0.5 |
||||||
Breaking strength(kN/m) |
5 |
7.5 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
MD, TD |
CBR Bursting strength(kN) |
1.1 |
1.5 |
1.9 |
2.2 |
2.5 |
2.8 |
3.0 |
|
Tearing strength(kN) |
0.15 |
0.25 |
0.32 |
0.40 |
0.48 |
0.56 |
0.62 |
MD,TD |
Remark |
Special specification, according to your demand |
|||||||
Anti-static water pressure designated value(MPa)
Thickness (mm ) |
0.2 |
0.3 |
0.4 |
0.5 |
0.6 |
0.7 |
0.8 |
One textile one membrane(mm) |
0.4 |
0.5 |
0.6 |
0.8 |
1.0 |
1.2 |
1.4 |
|
Two textiles One membrane(mm) |
0.5 |
0.6 |
0.8 |
1.0 |
1.2 |
1.4 |
1.6 |
