Solar Charge Controller

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

GW-10A-I

Dezhou Greatway Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name GW

Model Number GW-10A-I

Application Solar System Controller

Rated Voltage 12V

Maximum Current 10A/20A/30A

Specifications

solar charge controller:PWM solar charge controller
-MCU smart control
-12V/24V auto adapt,30A
-light+(1-13)hours time con

Advantages:

Solar charge controller

pwm solar controller

1.The charge controller adjusts itself automatically to 12V or 24V system voltage.

2.Clear,readable display of the state of charge.

3.Programmable Nightlight Function.

4.Detects day and night using the PV array.

5.Three states charge way.

6.Automatic adaptation to the ambient temperature.

7.Low voltage disconnected regulated by state of charge or voltage.

8.Biggest 16mm2 binding clamp

9.Complete Electronic protection.

10. Self-Test

Electrical Data

Model	MA01	MA02	MA03	-
Max.Solar Panel Current	10A	20A	30A	-
Max.Load Panel Current	10A	20A	30A	-
Norminal Voltage	12V/24V, automatic recognition
Boost Voltage	14.5V/29.0V
Equalization Voltage	14.8V/29.6V
Float Voltage	13.7V/27.4V
Low Voltage Disconnect Fuction	Controlled by state of charge: 11.4-11.9V/22.8-23.8V Controlled by voltage:11.0/22.0V
Load Reconnect Voltage	12.8/25.6V
Temperature Compensation	-4mv/(C*cell)
Max.Wire Size	16mm²
Ambient temperature	-40C to +50C
Internal protection	IP22
Material	PC
