960W 12v to 24v 40a Waterproof Boost /step up Dc-dc Power Converter /power Supply

Dezhou Greatway Import And Export Co., Ltd.
960W 12v to 24v 40a Waterproof Boost /step up Dc-dc Power Converter /power Supply thumbnail-1
960W 12v to 24v 40a Waterproof Boost /step up Dc-dc Power Converter /power Supply thumbnail-2
960W 12v to 24v 40a Waterproof Boost /step up Dc-dc Power Converter /power Supply photo-1
960W 12v to 24v 40a Waterproof Boost /step up Dc-dc Power Converter /power Supply photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
GW
Model Number:
GW-12S2440
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name GW
Model Number GW-12S2440
Output Power Other, 960W
Output Type Single
Size 200*127*63mm
Weight 2.85KG
Input Voltage DC 10-16V
Output Voltage DC 24V
Type DC/DC Converters
Output Current 40A



Product Description

 960W 12v to 24v 40a waterproof boost /step up dc-dc power converter /power supply960W 12v to 24v 40a waterproof boost /step up dc-dc power converter /power supply



Our products are widely used in automotive, posts and telecommunications, communications, electricity, coal, aerospace, defense, surveillance systems, railway signals, medical equipment, instruments and meters, LED displays, cable TV and other fields.
Features:
1. 100% full power & stable current output
2. 100% Imported components
3. Wide input voltage from 10-16Vdc
4. Industry grade DC12V to DC24V step-up  converter, high efficiency up to 96%
5. 100% waterproof & anti-shock protection, Ultra compact size, light weight
6. According: CE/RoHS, IP68 design
7. Die-cast aluminum shell, epoxy potting, Cooling by free air convection
8. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circiut. Auto-recovery when device is back to normal operating
9. Non-Isolated Module,
10. 1 year warranty, lifetime up to 100,000 hours.

960W 12v to 24v 40a waterproof boost /step up dc-dc power converter /power supply





Specifications:



Specifications:

Model

GW-12S2440

Input rated voltage

12V DC

Input voltage range

10-16V DC

Efficiency

97% (half load), 96% (full load)

Output voltage

24V DC

Output current

40 Amps

Output rated power

960 Watts

Output peak power

1000 Watts

Voltage regulation

< 1%

Load regulation

< 2%

Ripple (Full load test)

< 150mV

No-load current

50~60mA

Working temperature

-40°c ~ +80°c

Waterproof rating

IP68

Over-voltage protection

YES

Over-current protection

YES

Over-temperature protection

YES

Short-circuit protection

NO

Machine size

200*127*63mm

Package size

250*150*100mm

N. Weight

2.5kg

G. Weight

2.85kg

Cooling way

Free air convection

Other

Carton packaging
