Features:
1. 100% full power & stable current output
2. 100% Imported components
3. Wide input voltage from 10-Vdc
4. Industry grade DC12V to DC36V step-up converter, high efficiency up to 96%
5. 100% waterproof & anti-shock protection, Ultra compact size, light weight
6. According: CE/RoHS, IP68 design
7. Die-cast aluminum shell, epoxy potting, Cooling by free air convection
8. Protections: Over-current, Over-voltage, Over-temperature, Over-load and Short-circiut. Auto-recovery when device is back to normal operating
9. Non-Isolated Module,
Applications:
Trucks,Golf Carts,Forklifts,Buses,Loaders,Logging Vehicles,Wind Power System,Solar Power System,Electromotor,Telecommunications,Boat & Yacht,and so on...
Model |
GW12S3620 |
Input rated voltage |
12V DC |
Input voltage range |
10-18V DC |
Efficiency |
>96% |
Output voltage |
36V DC |
Output current |
20Amps |
Output rated power |
720Watts |
Output peak power |
130% |
Voltage regulation |
< 1% |
Load regulation |
< 2% |
Ripple (Full load test) |
< 100mV |
No-load current |
< 30mA |
Working temperature |
-30℃~ +80℃ |
Waterproof rating |
IP68 |
Over-voltage protection |
YES |
Over-current protection |
YES |
Over-temperature protection |
YES |
Short-circuit protection |
YES |
Machine size |
182*127*63mm |
Package size |
220*151*80mm |
N. Weight |
1.6Kg |
G. Weight |
1.7g |
Heat dissipation method |
Die-cast aluminum housing,Free air convection |
|
