6000W HF/PFC Battery Charger
Advantages
1. Internal integrated PFC, no pollution to electric network,
avoids shocking on electric network from heavy current.
2. Wide input voltage range AC85V~AC265V available for
worldwide requirements, convenient for electric-network
fluctuation and vehicles exportation.
3. High with 93% above efficiency while only about 80%
efficiency the traditional chargers can meet.
4. Intelligent temperature compensation function in the charging
process, preventing the damage to battery caused by charge-off
or charge due, greatly extending the lifespan of the battery.
5. Fully-sealed and water-proof, protection class IP46. Shock
resistance treatment made inside makes vibration-proof level up
to SAEJ1378 that can fully meet the standard of automobile
appliance usage.
6. Available for various kinds batteries like lead-acid, LiFePO4
battery etc., Flexible and programmable of the charging mode
and preset in 10 unique algorithms. Equipped with CAN
communication interface to realize real-time communication with BMS
Protection Features
1. Thermal Self-Protection: When the internal
temperature of the charger exceeds 75°C, the charging
current will reduce automatically. If exceeds 85°C, the
charger will shutdown protectively. When the internal
temperature drops, it will resume charging automatically.
2. Short-circuit Protection: When the charger encounters
unexpected short circuit across the output, charging will
automatically stop. When fault removes, the charger will
re-start in 10 seconds.
3. Reverse Connection Protection: When the battery is
polarity reversed, the charger will disconnect the internal
circuit and the battery, the charging will stop and avoid
been damaged
4. Input Low-voltage Protection: When the input AC
Voltage is lower than 85V, the charger will shutdown
protectively and automatically resumes working after the
volt is normal again
|
Lead acid Battery charger |
Lithium Battery charger |
Output voltage Nominal |
Output voltage Maximum |
Output current Maximum |
GWCH-48-105 |
GWCH-H66-105 |
48V |
66V |
105A |
GWCH-60-90 |
GWCH-H82.6-90 |
60V |
82.6V |
90A |
GWCH-72-75 |
GWCH-H96.2-75 |
72V |
96.2V |
75A |
GWCH-84-63 |
GWCH-H112-63 |
84V |
112V |
63A |
GWCH-96-54 |
GWCH-H130-54 |
96V |
130V |
54A |
GWCH-108-48 |
GWCH-H144.7-48 |
108V |
114.7V |
48A |
GWCH-120-45 |
GWCH-H168-45 |
120V |
168V |
45A |
GWCH-144-36 |
GWCH-H192-36 |
144V |
192V |
36A |
GWCH-156-33 |
GWCH-H208-33 |
156V |
208V |
33A |
GWCH-180-27 |
GWCH-H233.3-30 |
180V |
233.3V |
30A |
GWCH-192-27 |
GWCH-H243-27 |
192V |
243V |
27A |
GWCH-216-24 |
GWCH-H289.5-24 |
216V |
289V |
24A |
GWCH-240-21.6 |
GWCH-H337-21.6 |
240V |
337v |
21.6A |
GWCH-288-18 |
GWCH-H389-18 |
288V |
389v |
18A |
GWCH-312-16.5 |
GWCH-H417-16.5 |
312V |
417v |
16.5A |
