Glass Straight Line Double Edging Machine

Glass Straight Line Double Edging Machine thumbnail-1
Glass Straight Line Double Edging Machine thumbnail-2
Glass Straight Line Double Edging Machine photo-1
Glass Straight Line Double Edging Machine photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SANKEN
Place of Origin:
China
Model Number:
SKDE-4020A/SKDE-4020B
Contact Supplier Request Quote Chat Now
Sanken Glass Machinery., Ltd.(China.)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
100 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SANKEN
Place of Origin China
Model Number SKDE-4020A/SKDE-4020B
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty The quality guarantee period for all the machine is one year, any damage on the electric parts during the quality guarantee period can be maintained or replaced free, (Except in the course of usage, damage due to human errors).
Condition New
Machine Type Glass Edging Machine

&K series of excellent Glass Straight Line Double Edging Machine is used to grind two parallel of glass edges at the same time, with PLC control, it has the advantages of high accuracy, high working efficiency and easy operation. Because of our special conveying design, it will not have scratch mark on glass surface after processing. The optional width can be 1500mm, 2000mm, 2500mm, 3000mm, 4000mm, 4500mm. Each of the machine is equipped with totally 18, 20(22) spindles with 9, 10(11) at each side. Grinding and polishing can be done perfectly with only one time processing. It is our best seller at present.

1. Max. processing width: 4000mm

2. Min. processing size: 300x300mm

3. Total motors: 20pcs

4. Processing thickness of glass:3~25mm

5. Processing speed:0.4~4.8m/min

6. Compressed air consumption: 1L/min

7. Pressure:6kg/CM2

8. Total power: 45kw

9. Weight: 58000kgs


Product Tags: Glass straight line pencil double edger , Glass straight line round double edger , glass double edging machine for flat glass
