Massage Tub A430 for Family Outdoor Spa

STANDARD SYSTEM

SPECIFICATIONS:

Model No.: A430

Loading Quantity:

7 sets / 20'GP

14 sets / 40'HQ

Gross Weight: 319kgs

Net Weight: 281kgs

Volume: 4.00CBM

Dimensions (L x W x H):

205 x 165 x 80 cm

Seating Capacity:

3 adults

Lounge Seat (s):

1

Water Capacity:

776 liters

Dry Weight:

281 kg

Filled Weight:

1,095 kg

Spa Shell Material(USA):

Lucite® Acrylic (Standard Shell Colors: Alba, Sterling silver & Navy)

Spa Cabinet Material:

PS Wood-Plastic Composite Panels

Cabinet Frame:

Preserve Woods+ stainless steel

Bottom (Pedestal Base):

PVC Plastic sheet

Jet Ring Trim(USA):

Dark Grey Plastic

Total Jets (pcs):

52

5" Rotational Jets (pcs):

3

5" Massage Jets (pcs):

1

3" Directional Jets (pcs):

4

2" Rotational Jets (pcs):

20

2" Directional Jets (pcs):

4

1" Directional Jets (pcs):

19

Ozone Jets

1

Air jets(pcs) (Optional):

6

Pump 1(CE, TUV Approved):

One-speed / 3.0HP

Pump 2(CE, TUV Approved):

One-speed / 3.0HP

Circulation Pump (CE, TUV Approved):

1 x 0.5HP

Heater(CE, UL Approved):

1 x 3.0kW

Lighting(ETL Approved):

Multi-colored LED Underwater Light

Ozone Water Purification System:

Yes

Electrical Requirements:

220-240V/50Hz, 26A Max.

Suctions(UL Approved):

2 x 200GPM, 3 x 94GPM

Filter Size:

100sq.ft.

Diverter Valve(pc):

1

Air Control Valves (pcs):

2

EVA Spa Pillows(pcs):

3

Bottom Drain(pc):

1

Drain Valve(pc):

1

Using spray insulating PU foam (USA) on the under-side of the spa shell:

Yes

Sparelax Control System

Yes
