Crispy fried snack machine/Fried Flour Bugles Snack Food Machines/small snack food machine
Main products : Tri-D , screw , shell , round tube , square tube , ring , cartoon shape and sport shape etc.
Detail information:
1: Produced by single screw extruder CYS-100 , the capacity is 80-100 kg/h . If you want a 200kg/h capacity , we will configure 2 extrudersand 2 cutting machines for the production line the other part is the same.
2: The Tri-D food line can use potato starch , corn starch , cassava starch , wheat flour etc. Can you tell me what material will you use ?
3: We use stainless steel 201 as material .
4: The motor , electrical devices and components , frequency converter we use Lijiu(Chinese top brand) .
5: Energy use electrical ,Please tell me the Input Voltage in your country , Chinese Input Voltage is 380V/ 50Hz , If it is different from yours , we will adjust it .
6: Do you need packing machine ? Please tell me the bag size you need .
The Flowchart as flows:
mixing→extruding→cutting→cooling → drying→frying→ flavoring
Include machines:
Mixer---screw conveyor---single screw extruder CYS100---cutting machine---roasting oven---frying machine---flavoring machine
Price for chips production line (common) : 80-100kg/h
| equipmen | QUANTITY |
TECHNICAL PARAMETER |
IMAGE |
FUNCTION |
|
1 |
Mixer |
1 |
Power:4kw Output: 50kg/tube Size: 0.8*0.7*1.2m |
|
To mix the raw materials with the water
|
|
2 |
Screw Conveyor 3m |
1 |
Power:1.1kw Output: 100-500kg/h Size: 0.2*0.8*3.0m |
|
To send the materials to the extruder |
3 |
CYS-100 single screw extruder |
1 |
Power:22kw Length-diameter ratio: 1640/100 Output:80-100kg/h Size: 2.5*1.0*2.0m |
|
To extrude and inflate the food. the main machine of the line |
4 |
cutting machine For cutting 3D/screw shape food |
1 |
Power:1.1kw Output:100-500kg/h Size: 2.5*1.5*0.8m |
|
To shape the food, like3D, screw etc |
5 |
Roasting oven (3layer/ 5m electrical) |
1 |
Power:27.5kw Output:100-250kg/h Size: 5.0*1.3*2.0m |
|
To dry the food
|
6 |
Fryer 4m |
1 |
Power:65kw Output:300-500kg/h Size:4.0*1.3*2.0m |
|
To fry the food crisp |
|
Batch fryer |
1 |
Power:4kw Output:150kg/h Size: 4.55*1.98*2.0m |
|
||
7 |
Single roller flavoring system
|
1 |
Power:3kw Output:180kg/h Size: 4.0*0.8 *1.6m |
|
To flavor the food |
|
Payment term: 1. 40% of total payment as the deposit,we will finish the machine within 40 days. 2. 60% of total payment before making delivery the Equipment to Buyer’s plant. Package: Wooden case for export, fit for multiple handing and long distance marine shipping. Delivery time: Seller should get all the goods ready and ship the goods to the destination port within 40 days after receiving the total amount price. Quality guarantee terms: equipment shall be guaranteed 12 month, without destroyed by some people. Enclosed the whole line, we will give you some spare parts, such as heating ring, spanner, etc. for free. The spare parts shall be supplied at preferential price for an extended long time. Installation and training: we will send our engineer to install and train in your company, on condition that you should supply the go and return air tickets, the accommodation, the food for our engineers and also pay USD50 each person per day.
| |||||
