Animal feed processing machinery
- 10 Set / Sets per Month
- Qingdao
- T/T
- 2024 New Double color Popular extruding dog treats making machine pet chew food processing line
- Double color Popular extruding dog treats making machine pet chew food processing line
- 2024 popular Dry Wet Various shapes flavors dog food pellet making extruder machine food pet pellet feed processing line
- Popular extruding dog treats making machine pet chew food processing line
- 2024 Popular High Quality Single screw extruding dog treats making machine pet chew food processing line
- 2024 new design Dry Wet Various shapes flavors dog food pellet making extruder machine food pet pellet feed processing line
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | CY |
Model Number: | CY65-VI | Application: | Dog | Voltage: | 380V 50HZ |
Power(W): | 22KW | Weight: | 1200kgs | Dimension(L*W*H): | 12*1.2*1.8m |
Certification: | CE ISO | Warranty: | 12months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
animal feed processing machinery :
the feed processing machinery is consist of:
1. mixer
2.double-screw Extruder
3. air conveyer
4. five_layer roasting oven
5.Automatic flavoring machine
Technical Parameter:
Model: | CY65-VI double-screw inflating line | CY85-II double-screw inflating line |
Installed capacity: | 70 kw | 140 kw |
Power consumption: | 45 kw | 110 kw |
Ouput: | 120-150KG/H | 300-400KG/H |
Size: | 12×1.2×1.8 M | 13×1.2×1.8 M |
The pet food processing line
Extruding and inflating technology is that it can supply us un-image processing measure, combine with market demand, pet food machinery produced by Chenyang Company, adopts particular process technics and equipment scheme. The final products with fashion shape, specail taste, scientific nutrition combinative, easily to absorb and is quite popular to the pet market.
The model is :CY70-VI Pet food processing line.
The capacity of the line is:200-250kg/h
The procedure is mixing→extruding→drying→ flavoring
The detailed information
NO | Machine
| Motor Power
| Capacity
| dimension
| Quantity
| Function
|
1 | Milling machine | 7.5kw | 200-300kg/h | 3.0*1.2*3.5m | 1set | To mill corn into powder |
2 | Silo |
| 5 Ton/once | 1.8*5.3m |
| To save the corn powder |
3 | mixer | 4KW | 50kgs /once time | 0.8*0.7*1.5m | 1set | To mix the raw materals with the water |
4 | screw conveyer
| 1.1KW | 150kg/h | 3*0.8*2m | 1set | To send the materials to the extruder |
5 | CY70-II Double screw extruder | 30KW
| 200-220kg/h | 2.8*1.0*1.8m | 1set | To extrude and inflate the food.the main machine of the line |
6 | Shifter
| 0.55kw | 150kg/h | 1.6*1.0*1.2m | 2set | To select good pet food, one shifter put after extruder, another shifter put after dryer. |
7 | Large hoister
| 0.37KW | 150kg/h | 4.1m height | 1set | To send the food into the dryer |
8 | 5layer 5meter dryer | 45kw | 180-300kg/h | 5.0*1.2*3.5M | 1set
| To dry the food
|
8 | Double roller flavoring system | 1.5kw | 150-200kg/h | 2.1*1.1*1.9m | 1set | To flavor the snack food with flavoring materials |
Payment term:40% of total amount by T/T in advance as down payment, we will complete the whole line within 45 days, the rest 60% paid by T/T after the buyer test the machine in seller’s factory or we take video for buyer and before we make delivery.
Package: Wooden case for export, fit for multiple handing and long distance marine shipping.
Delivery time: Seller should get all the goods ready and ship the goods to the destination port within 40 days after receiving the total amount price.
Quality guarantee terms: equipment shall be guaranteed 12 month, without destroyed by some people. Enclosed the whole line, we will give you some spare parts, such as heating ring, spanner, etc. for free. The spare parts shall be supplied at preferential price for an extended long time.
Double screw extruder mainly contains :feeding systems, extruding systes, cutting systems, heating systems,gearing systems, lubricating system, control system. Main features:
A:extruding systems: the screw with high wear-resistant performance by using alloys steel materials(38ARMOAL), screw is made by special technique, is able to bear grinding, steady and reliable, longer using life.according to different screw design rate to full different technology request.
B:Cutting systerm :the cutting system adopt center cutting,high precisional orientationto make sure that the cutting knife keep a parallel place with the cyclostyle avoidthewear and tear, the head of the cutting knife like a spring ,so that the symmetrical pressure make the cutting very easy ,and cutting the productes size lookes more perfect.especially avoid the metal powder go into the peroducts.
C:Heating system:use the far infrared heating manner,circulate water for cooling,to guarantee the extruder running safely.
D: Gearing system:the main motor,feeding ,cutting,liquid feeding system of the extruder all use the frequency to control the speed ,the frequency we use is : DELTA,the gear we use hard gear,enough strong,running placidiy and low noise.
E: lubricating system:have single oil box circle system,and have a inspect equipment for the press meter.
F: Controling system :consists of feeding system, extruding system and cutting system adopts frequency speed-controlling with high automation and stable per-formation.
G: Feeding system:according to different materials, to choose the relative single or double screw feeding system, the materials should be uniformity and stable.
H: Cooling system: we add the cooling system on each zone,it can control the temperature well.
CY70-II double screw extruder
main motor:30 KW
cutting motor :0.37 kw
feeding motor:0.75kw
oil control motor:0.75kw
capacity: 200-220kg/h
size: 2.8*1.0*1.8m
Screw diameter:70mm
Screw length:1410mm
Barrel/Screw materials:38 ARMOAL
The barrel and screw HRC(High-Rupturing capacity):60
The extruder has the gear box which can make the extruder runs more steady.
2. diesel dryer
The whole equipment belt is made of stainless steel, and match food hygiene export standard requirement;
The construction tightly packed is reasonable, installed area is small and the operation maintains is easy;
The temperature and speed is adjustable automaticlly to realize best effect.
These series of roasting oven are widely used, it is used for drying all kinds of stick,piece, grain, etc. shapes inflated of snack food, the user can choose different types of dryer according to layer, length, or energy.
The food pictures as follows(we can produce various shapes pet food by changing the moulds):
