Home > Products > pet food machinery > chews treats bone dog snack food making machine
chews treats bone dog snack food making machine
- 25 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A
- 2024 New Double color Popular extruding dog treats making machine pet chew food processing line
- Double color Popular extruding dog treats making machine pet chew food processing line
- 2024 popular Dry Wet Various shapes flavors dog food pellet making extruder machine food pet pellet feed processing line
- Popular extruding dog treats making machine pet chew food processing line
- 2024 Popular High Quality Single screw extruding dog treats making machine pet chew food processing line
- 2024 new design Dry Wet Various shapes flavors dog food pellet making extruder machine food pet pellet feed processing line
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | CHENYANG |
Model Number: | CYS-80/CYS-100 | Application: | Dog | Voltage: | 220V/380V |
Power(W): | 28-54kw | Weight: | it depends | Dimension(L*W*H): | 12000*1200*2000mm |
Certification: | CE Certificate | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
chews treats bone dog snack food making machine
1:Product Description
Dog chewing food machine can make dog chewing food is made of many kinds of different materials with scientific configuration and extrusion in the extruder. This kind of product can be made into a variety of shapes such as stick, bone, etc. This kind of food not only provides nutrition to dogs, like protein, fat, vitamin, etc, but also satisfies the dog nature hobby, benefits its strong teeth, cleans mouth and teeth, and prevents disease.
2: Process and follow chart
Mixer---Screw conveyor--- Single screw extruder---Cooling machine---Cutting machine--- Hoister---Drying oven
3:The Various Parts Of Details Technical Parameter:
Model | Installed powder | Power consumption | Output | Dimension |
Mixer | 4kw | 3kw | 40kg/time | 1200*650*1100mm |
Screw conveyor |
1.1kw |
0.8kw |
100-200 kg/h |
3000*800*2800mm |
CYS-100 single screw extruder |
45kw |
30kw |
100kg/h |
3200*1050*1960mm |
Cooling |
0.75kw |
0.5kw | 100-200 kg/h |
6000*400*800mm |
Cutting machine |
2.2kw |
1.8kw |
100-200 kg/h |
1200x 700x 1350mm |
Hoister |
0.75kw |
0.5kw |
100-200 kg/h |
1000*300*1500 mm |
Drying oven |
65kw(elec.) |
40kw |
100-200 Kg/h |
5000×1400×2000 mm |
7.5kw(gas/oil) |
12L/h |
4:Samples:
5:Packaging and Shipping
Wooden cases. well sealed and strong enough for long-term trip;suitable for loading & unloading by forklift or upon clients' demands.
Shipping:
Delivery date:within 25 working days after ordering.
Port:Qing dao .
6:Company Information
7:About installation and after-sale service system
1. We can provide factory layout according to customer’s factory size in advance.
2. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the processing line arrived your country, and we will send two engineers to go and help you to install the line, teach your worker(3-4 workers) how to operate the line, until your worker know the line well.
3. Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
4. Our engineers can provide basic formula for producing the core filling food and help customer to produce good quality food according customer’s detailed formula.
5. We provide the spare parts will at preferential price for an extended long time.
6. other item:
a). Free consultation service before, during, and after sales;
b). Free project planning and design services;
c). Free debugging of equipment until everything is functional;
d). Free management of equipments' long distance shipping;
e). Free training of equipment maintenance and operating personally;
f ). Free new production techniques and formulas;
g). Provide 1 year complete warrantee and life-time maintance service;
8:Contact with us
If you have any question about our product or any other question about this kind of machine ,please contact with us,we will try our best to help you with your problems.
