Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Welding Machine > Steel Wire Cage Forming Machine

Steel Wire Cage Forming Machine

Name: Steel Wire Cage Forming Machine
Brand: CICQ
SKU: 141990372
Availability: InStock

Steel Wire Cage Forming Machine thumbnail-1

Steel Wire Cage Forming Machine thumbnail-2

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

CICQ

Current:

100KVA

Contact Supplier Request Quote Chat Now

Shandong Zhongzhiqiao Heavy Industry Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name CICQ

Current 100KVA

Weight 2000kgs

Usage Welding Machine

Certification ISO9001:2008

After-sales Service Provided Engineers available to service machinery overseas

This machine consist of four parts of driving systems,inclusive master plate of rotation,plate of push reinforcing steel,expansion diameter part,and welding machine.The four parts are drived by independent electrical motor.The full variable frequency control ensures that the span of the latitude steel and the angle of the spigot won't change along with the welding speed.Adjustment the ratio of motor speed can change the span of latitude steel,and angel of spigot.This machine can weld different diameter cages via adjustment of location and position of the master plate and welder.

ITEM	PARAMETERS OR VALUE
Cage diamter	300-1200mm
Cage length	1000-4000mm
Specifications of steel wire	Longitude wire dia.:3.5-6mm Latitude wire dia.:4-6mm
Quantity of longitude steel	12 pcs
Span between latitude steel	20-150mm
Angle of spigot	10-25
Rotation speed of master plate	0-10 r/min
Power of motor	0.55+1.1+2.2+0.75kw
Power transformer of welder	100KVA
