Help CenterJUANYONG 4"sewage Pump for Sewage Pumps Supplier Made in China
Related Products
-
JUANYONG 3"sewage Pump for Sewage Sewage Pumps ManufacturerUS$ 58 - 68MOQ: 5 Sets -
JUANYONG 2"(2HP50) High Pressure Water Pump of Pressure Water Pump Water PumpsUS$ 40 - 50MOQ: 5 Sets
-
JUANYONG 3"self Priming Water Pump Diesel Engine Water Pump High Pressure Water PumpUS$ 65 - 75MOQ: 5 Sets
-
High Pressure Water Pump High Lift Water Pump Fire Water Pump PriceUS$ 30 - 40MOQ: 5 Sets
-
KINGWAY 1Inch Self Priming Pump, Self Priming Water Pump, Self Priming Sewage PumpUS$ 10 - 15MOQ: 1 Set
Product Description
Performance curve
Parameter
ITEM |
WB100 |
Outlet Size(mm) |
100 |
Inlet Size(mm) |
100 |
Speed(rpm) |
3600 |
Displacement Q.max(m3/h) |
68 |
Lift H.max(m) |
20 |
Suction(m) |
5 |
Engine Model |
190F |
Serial number |
Name
|
Number |
1 |
Water pump cover |
1 |
2 |
Aluminum flat washer φ8×φ16×1.5 |
5 |
3 |
Bolt M8×45 GB5787 |
4 |
4 |
Pump sealing ring |
1 |
5 |
Mechanical seal / ceramic |
1 |
6 |
Impeller |
1 |
7 |
Eddy shell |
1 |
8 |
Eddy shell sealing ring |
1 |
9 |
Water pump body |
1 |
10 |
Outlet gasket |
1 |
11 |
The water outlet joint |
1 |
12 |
Bolt M10×30 |
8 |
13 |
Rubber plug gasket |
2 |
14 |
Threaded plug pump |
2 |
15 |
Inlet sealing gasket |
1 |
16 |
Inlet joint |
1 |
17 |
Pipe joint sealing gasket |
2 |
18 |
Pipe joint connecting nut |
2 |
19 |
Pipe joint |
2 |
20 |
Clamp |
3 |
21 |
The filtering orifices |
1 |
22 |
Filter cover |
1 |
23 |
T bolt |
4 |
Tianzhiyuan is actively expanding its existing business and assessing new opportunities throughout China and the
globe. Through various functions, we are working to provide the right products and services to customers domestic
and foreign.Now we are cooperating with LONCIN, RATO, Dajing, Lianlong etc. Tianzhiyuan is developing our
services according to the customer’s requirement.
