Help CenterFarm Irrigation Gasoline Water Pump With Aluminum Frame on 168F Engine
Related Products
-
Gasoline Fuel Pump With 168F Engine for Farm IrrigationUS$ 10 - 80MOQ: 5 Sets -
2"high Lift Petrol Water Pumps Made in ChinaUS$ 80 - 150MOQ: 5 Sets
-
50mm Outlet and Inlet Petrol Fire Fighting Water Pump Made in ChinaUS$ 80 - 150MOQ: 5 Sets
-
2016 Newest Products Diesel Water Pumps With Aluminum Body for Farm Irrigation Hot Sales ItemUS$ 10 - 80MOQ: 5 Sets
-
Made in China Aluminum Cam&Groove House Coupler Type B 1/2-8 InchUS$ 2 - 20MOQ: 200 Pieces
Gasoline Water Pump (TZYGWP100-188)
1)Max.Lift: 30m
2)Max.Flow: 66000L / h
3)Easy maintenance,high quality
Details Description
Technical Specs | Engine Type: 154-SV |
MODELS | TZYGWP50 |
Types | Self-Priming |
Inlet Diameter (mm) (Inch) | 50 (2”) |
Outlet Diameter (mm) (Inch) | 50 (2”) |
Lift Head (m) | 15 |
Suction Length (m) | 5 |
Max. Flow (m3/h) | 15 |
Engine | TL154F/P |
Displacement (cc) | 105 |
Starting System | Recoil |
Packing Size (LxWxH) (mm) | 450x320x405 |
Net Weight (Kg) | 18 |
Others series Gasoline Water Pump
Model | WP20 | WP30 | WP40 | |
Water pump | Suction/Discharge Dia. (mm) | 50mm/50mm | 80mm/80mm | 100mm/100mm |
Max. Lift (m) | 28m | 28m | 29m | |
Max. Suction (m) | 8 | |||
Max. Flow/Efficiency (m³/h) | 36 | 66 | 108 | |
Rev (rpm) | 3600 | |||
Suction time | 90s/5mm | 120s/5mm | 50s/5mm | |
Engine | Model | GX160 | GX270 | |
Rated output (kw/rmp) | 4.0/3600 | 4.0/3600 | 5.9/3600 | |
Ignition system | Transistor Ignition | |||
Output shaft direction | Counter-clockwise (from output pin) | |||
Idle speed | 1440 | |||
fuel tank capacity (L) | 3.5L | 6L | ||
Dim&N.W. | N.W. (kg) | 22 | 28 | 47 |
Length x width x height (mm) | 471x380x375 | 490x385x460 | 610x425x565 | |
Features:
1.Good engine will be used and lightweight die-cast aluminum pump delivers high volume of water.
2.The highly effective mechanical seal with special carbon ceramics provide extra durability.
3.The entire unit is protected by a sturdy rollover pipe frame.
4.Guaranteed suction head of 7 meters.
Applications:
1.Sprinkling for field irrigation.
2.Irrigation of paddy fields.
3.Orchard calculation.
4.Pumping water from wells.
5.Feeding or draining water to /from ponds or troughs.
6.Feeding or draining water on fish farms.
7.Washing cattle,barns or agricultural tools.
8.Feeding water into water reservoirs.
