Gas powered water pump hot item of 6.5hp centrifugal water pump
- 1500 Set / Sets per Month
- Chongqing or Shanghai Port
- T/T L/C D/P D/A
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Chongqing, China | Brand Name: | OTHERS | Model Number: | TZYG2HP-168F |
Theory: | Other, Self- Priming | Structure: | Single-stage Pump | Usage: | Water |
Power: | Hydraulic | Standard or Nonstandard: | Standard | Fuel: | Gasoline |
Pressure: | Low Pressure | Application: | Other, Watering & Irrigation |
Product Description
Gasoline Water Pump (TZYGWP100-188)
1)Max.Lift: 30m
2)Max.Flow: 66000L / h
3)Easy maintenance,high quality
Details Description
Technical Specs | Engine Type: 168F |
MODELS | TZYGWP50 |
Types | Self-Priming |
Inlet Diameter (mm) (Inch) | 50 (2”) |
Outlet Diameter (mm) (Inch) | 50 (2”) |
Lift Head (m) | 15 |
Suction Length (m) | 5 |
Max. Flow (m3/h) | 15 |
Engine | TL154F/P |
Displacement (cc) | 105 |
Starting System | Recoil |
Packing Size (LxWxH) (mm) | 450x320x405 |
Net Weight (Kg) | 18 |
Others series Gasoline Water Pump
Model | WP20 | WP30 | WP40 | |
Water pump | Suction/Discharge Dia. (mm) | 50mm/50mm | 80mm/80mm | 100mm/100mm |
Max. Lift (m) | 28m | 28m | 29m | |
Max. Suction (m) | 8 | |||
Max. Flow/Efficiency (m³/h) | 36 | 66 | 108 | |
Rev (rpm) | 3600 | |||
Suction time | 90s/5mm | 120s/5mm | 50s/5mm | |
Engine | Model | GX160 | GX270 | |
Rated output (kw/rmp) | 4.0/3600 | 4.0/3600 | 5.9/3600 | |
Ignition system | Transistor Ignition | |||
Output shaft direction | Counter-clockwise (from output pin) | |||
Idle speed | 1440 | |||
fuel tank capacity (L) | 3.5L | 6L | ||
Dim&N.W. | N.W. (kg) | 22 | 28 | 47 |
Length x width x height (mm) | 471x380x375 | 490x385x460 | 610x425x565 |
Features:
1.Good engine will be used and lightweight die-cast aluminum pump delivers high volume of water.
2.The highly effective mechanical seal with special carbon ceramics provide extra durability.
3.The entire unit is protected by a sturdy rollover pipe frame.
4.Guaranteed suction head of 7 meters.
Applications:
1.Sprinkling for field irrigation.
2.Irrigation of paddy fields.
3.Orchard calculation.
4.Pumping water from wells.
5.Feeding or draining water to /from ponds or troughs.
6.Feeding or draining water on fish farms.
7.Washing cattle,barns or agricultural tools.
8.Feeding water into water reservoirs.
Advantages we have:
A. Experienced water pump products supplier.
B. Professional design team and sales department for your service.
C. Alibaba golden supplier, factory recognized by "CE/IS9001"and so no.
D. 7/24 service for you all the question will be dealed within 24 hours.
Benelit you got:
A.Stable quality-coming from good material and technic.
B.Lower price-not cheapest but the lowest at the same quality.
C.Good service-satisfactory service before and after sale.
D.Delivery time10-15 days for mass production.
Business type:manufacturer,trading company.
Location:chongqing,china(mainland).
Year established:2010.
Company certifications:
Main products:chemical pumps,sewage pumps,self priming drag pumps,self priming high lift pumps,self priming pumps.
Our philosophy is to provide our clients with a wide choice of quality products and unprecedented services,we assure our clients of a mutually beneficial relationship as we look forward to developing a long term strategic partnership with your esteemed organization.
