Help CenterSingle -4 Stroke Gasoline Driven 4 Inch Self Priming Water Pump for Irrigation Self Priming Water Lift Pump
Related Products
-
2 Inch Gasoline Powered Water Pump With 168F Engine for Orchard CultivationUS$ 10 - 80MOQ: 10 Sets -
168F Engine Gasoline 2 Inch Petrol Water Transfer Pump Fire FightingUS$ 80 - 150MOQ: 10 Sets
-
5hp Petrol Water Transfer PumpUS$ 10 - 80MOQ: 10 Sets
-
5hp Diesel Engine Driven Centrifugal Self Priming Water Pump for IrrigationUS$ 60 - 80MOQ: 10 Sets
-
170F Engine Gasoline Drag Water Pumps With 2&3 Inches for Tank Irrigation Hot Sales Items of AgricultureUS$ 80 - 150MOQ: 5 Sets
Gasoline Water Pump (TZYGWP100-188)
1)Max.Lift: 30m
2)Max.Flow: 66000L / h
3)Easy maintenance,high quality
Details Description
Power Options |
Sewage Water Pump 13HP |
Models |
TZYGWP100 |
Types |
Self-Priming |
Inlet Size (mm)(In.) |
100 (4’) |
Outlet Size (mm)(In.) |
100 (4’) |
Lift Head (m) |
30 |
Suction Length (m) |
6 |
Max. Flow (m3/h) |
80 |
Engine |
TL188F/P |
Fuel Options |
Gasoline |
Displacement (cc) |
390 |
Starting System |
Recoil or Key |
Others series Gasoline Water Pump
Model |
WP20 |
WP30 |
WP40 |
|
|
Water pump |
Suction/Discharge Dia. (mm) |
50mm/50mm |
80mm/80mm |
100mm/100mm |
Max. Lift (m) |
28m |
28m |
29m |
|
Max. Suction (m) |
8 |
|||
Max. Flow/Efficiency (m³/h) |
36 |
66 |
108 |
|
Rev (rpm) |
3600 |
|||
Suction time |
90s/5mm |
120s/5mm |
50s/5mm |
|
Engine |
Model |
GX160 |
GX270 |
|
Rated output (kw/rmp) |
4.0/3600 |
4.0/3600 |
5.9/3600 |
|
Ignition system |
Transistor Ignition |
|||
Output shaft direction |
Counter-clockwise (from output pin) |
|||
Idle speed |
1440 |
|||
fuel tank capacity (L) |
3.5L |
6L |
||
Dim&N.W. |
N.W. (kg) |
22 |
28 |
47 |
|
Length x width x height (mm) |
471x380x375 |
490x385x460 |
610x425x565 |
|
Features:
1.Good engine will be used and lightweight die-cast aluminum pump delivers high volume of water.
2.The highly effective mechanical seal with special carbon ceramics provide extra durability.
3.The entire unit is protected by a sturdy rollover pipe frame.
4.Guaranteed suction head of 7 meters.
Applications:
1.Sprinkling for field irrigation.
2.Irrigation of paddy fields.
3.Orchard calculation.
4.Pumping water from wells.
5.Feeding or draining water to /from ponds or troughs.
6.Feeding or draining water on fish farms.
7.Washing cattle,barns or agricultural tools.
8.Feeding water into water reservoirs.
