Home > Electrical & Electronics > Inverter > Power Inverter > 560V/6A 98% Conversion Efficiency 2200Wsolar Water Pump Inverter
560V/6A 98% Conversion Efficiency 2200Wsolar Water Pump Inverter
US$ 368.65 - 399.65
MOQ: 5 Sets
Key Specifications
Get Latest Price
Brand Name:
YC-Solar water pump inverter
Model Number:
YCSBH0022
Output Power:
Other, 2200W
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Durable 1.5KW Solar Irragatting SystemUS$ 2,239.98 - 2,498MOQ: 1 Set -
370W Solar Submersible Well Pump for Home Drinking UsageUS$ 699.99 - 725MOQ: 1 Set
-
Lighting Global Certified LED Solar Lanterns With Mobile Charging Function!US$ 22.88 - 23.88MOQ: 1000 Pieces
-
Solar Pumping System Used!275W Mono-Crystalline Solar Modules of Full PowerUS$ 0.6 - 0.8MOQ: 1 Piece
-
TC160NB-16T PV Array Combiner Box/8 in 1out Combiner Box/AC Distribution BoxUS$ 200 - 500MOQ: 1 Set
Brand Name
YC-Solar water pump inverter
Model Number
YCSBH0022
Output Power
Other, 2200W
Output Type
Dual
Size
650*450mm
Weight
12kg
Input Voltage
560V
Output Voltage
380V 3 phase
Output Frequency
0~50HZ
Output Current
5A
Specifications
1.MOQ:1 set solar pump inverter;2.ISO,CE;
3.With Mppt charge controller;
4.Pure sine wave;
5.Sample available but charged
2200W solar water pump inverter
| SOLAR WATER PUMP INVERTER | |||||||
| Model | YCSBH0015 | YCSBH0022 | YCSBH0030 | YCSBH0037 | YCSBH0055 | YCSBH0075 | YCSBH0110 |
| Max. input voltage(V) | 800 | ||||||
| MPPT voltage range(V) | 300-750 | ||||||
| Recommend input work voltage(V) | 560 | ||||||
| Max. input current(A) | 4 | 6 | 8 | 11 | 15 | 21 | 28 |
| Max. MPPT efficiency/ | 97% | ||||||
| Recommend pv array power(kw) | 1.7 | 2.3 | 3.3 | 4.5 | 6.0 | 8.3 | 11.3 |
| Input road | 2 | ||||||
| Max, drive motor power(kw) | 1.1 | 1.5 | 2.2 | 3 | 4 | 5.5 | 7.5 |
| Rated output voltage(V)/ | 380V 3 phase | ||||||
| Output frequency | 0~50/60Hz | ||||||
| Max. system efficiency | 98% | ||||||
| Operating temperature range | from-10℃ to +40℃ | ||||||
| Cooling method | Natural cooling + air cooling | ||||||
| Display | LCD | ||||||
| Altitude | 1000m,above 1000m need derate power | ||||||
| Meet the standards |
EN 50178; IEC/EN 62109-1; IEC 61800
|
||||||
Packaging & Shipping
cartons or wooden box.Or according to customer's need .Packing siez: 1000*800*600mm(1-3KW) ;1500*1215*600mm(4-6kw) .200pcs/20'ft ,400pcs/40'ft
standard ocean shipping
Company Information
Yunnan YAOCHUANG energy development co.,ltd.
Our Services
Solar panel, charge controller, inverter, rechargeable battery, LED light
Solar water pump system
Off grid solar generator system
Grid tie solar generator system
Wind & solar hybrid generator system
Customized solar energy system application according to your demand,feel free to contact Jackie:)
