Off grid solar system 5000W/48Vdc, 5000W/96Vdc, 10000W/96Vdc, 10000W/192Vdc mppt solar charge controller inverter

Specifications

mppt solar charge controller inverter
AC Output Voltage AC 220
5000W/10000W pure sine wave inverter
Motor frequency inverter

  Off grid solar system 5000W/48Vdc, 5000W/96Vdc, 10000W/96Vdc, 10000W/192Vdc mppt solar charge controller inverter

   mppt solar charge controller inverter motor frequency inverter







Feature

•  Toroidal transformer of light weight, small size, high conversion efficiency, low power consumption, good load capacity and load adaptability, etc.



•  AC input automatic voltage regulator (AVR), input voltage range of 145V ~ 275V.



•  Liquid crystal (LCD) display, backlight power saving mode. The main display real-time battery voltage, battery capacity, input and output voltage, output frequency, duty ratio, etc. Automatically switch the display according to different working conditions.



•  Multifunction intelligent operating system, icon-based menu operation, easy human-computer communication interface.



•  Function: System Language settings (in English), the timing settings (switch), the mode setting (mains operation overrides / battery operation mode priority), peak load shifting settings, time settings, display mode settings, restore factory settings and other feature settings.



•  Record Query: Fault records check, battery discharge time queries.



•  Having overload, battery overcharge, over discharge, output short circuit, over-temperature protection features.
•  Full SMD modular structure, stable performance, easy maintenance.

Rated Power	5000W	5000W
Battery Voltage	48Vdc	96Vdc
Battery Voltage range	42Vdc-60Vdc	84Vdc-120Vdc
Input Voltage(AC)	220Vac(145Vac-275ac)
Input Frequency	50Hz(45Hz-55Hz)
Output Voltage(AC)	220Vac(Battery mode±3%,Mains mode±10%)
Output Frequency	50Hz
Transfer Efficiency	≥85%	85%(100%load)88%(50%load)
Output Wave	Standard Sine Wave
Temperature	-10℃~ 50℃
Humidity	10%~ 90%(Non-condensing)
Model	JGN-I10000-96	JGN-I10000-192
Rated Power	10KW	10KW
Battery Voltage	96Vdc	192Vdc
Battery Voltage range	84Vdc-120Vdc	168Vdc-240Vdc
Input Voltage(AC)	220Vac(145Vac-275ac)
Input Frequency	50Hz(45Hz-55Hz)
Output Voltage(AC)	220Vac(Battery mode±3%,Mains mode±10%)
Output Frequency	50Hz
Transfer Efficiency	≥85%	85%(100%load)88%(50%load)
Output Wave	Standard Sine Wave
Temperature	-10℃~ 50℃
Humidity	10%~ 90%(Non-condensing)











Size(L×W×H)	460mm×246mm×445mm
Package Size(L×W×H)
NW(Kg)	33	33
GW(Kg)
Protection
Over Charge	Y
Low Voltage Protection	Y
Over Voltage Protection	Y
Overload Protection	Y
Short Circuit Protection	Y
Over High Temperature	Y
Model	JGN-I10000-96	JGN-I10000-192
Size(L×W×H)	560mm×328mm×598mm
Package Size(L×W×H)
NW(Kg)	65	65
GW(Kg)
Protection
Over Charge	Y
Low Voltage Protection	Y
Over Voltage Protection	Y
Overload Protection	Y
Short Circuit Protection	Y
Over High Temperature	Y
