Stand Solar Panel System 15kw Silent Solar Generator

System voltage

24V

48V

System current

80A

80A

  No-load loss

<20mA

<15mA

Solar energy input voltage

55V

100V

Over voltage protection

33.0V±1%

66.0V±1%

Over voltage recovery

30.0V±1%

60.0V±1%

Balancecharge voltage

29.2V±1%

58.4V±1%

Increase charge voltage

28.8V±1%

57.6V±1%

Float charge voltage

27.6V±1%

55.2V±1%

Charging return voltage

26.6V±1%

53.2V±1%

Over discharge protection voltage

22.2V±1%

44.4V±1%

Over discharge return voltage

25.6V±1%

51.2V±1%

Night identification voltage

6.0V±1%

12.0V±1%

Daytime identification voltage

14.0V±1%

28.0V±1%

Temperaturecmpensation

-4.0mv/℃/2V

Over-load, short circuit protection

1.25 times rating current 30S;1.5 times rating current 10S overload current protection

≥3 times rating current short circuit protection

Work temperature

-25℃to+60℃

Protection degree

IP30

Outline size

150mm*135mm*63mm
