Product Details
Capacity: | 80TON | Place of Origin: | Shanghai, China | Brand Name: | YUAO |
Model Number: | IF1T-R4A-IFCT-80T | Ice Shape: | Ice Block | Certification: | CE |
Product Description
cooling mini ice maker
Specifications
1.Edible Tube Ice Machine
2.Stable of production
3.Easy for storage
4.High reliability
5.CertificationCE
Tube ice machine application
1 Human consumption ice plant
2 Port ice plant
3 Coffee shop,bar,and hotel,etc
4 Supermarket,convenienience shop and restaurant,etc
5 Aquatic products and food fresh preservation
6 Logistic fresh preservation
7 Cgemical and concrete projects
Tube ice machine work conditions
Power supply: Full electric system complying with the general international standard
Ambient temperature: 33°C
Water supply temperature: 20°C (water quality should be pure,Water filter and softening is suggesteded for places with hard water quality.)
Tube ice specification: φ22,φ29,φ35,φ38 and φ41(standardard tube ice outer diameter,inner diametr 3mm-15mm )
Limit work comditions Ambient temp.:5°C~40°C; Water suppl:0.5°C~30°C.
Refrigrant: R22,R404A,R507A,R717
Tube ice machine features
1 High reliability and low fault failure
80% components of the tube ice maker system are world famous brand. Through decades of research and practice, the products can run continuously without fault and keep good run and stable ice output even in ambient temperature 5°C-4O°C. Special designed machine can even allow normal run in the most atrocious conditionns(-5°C-+56°C).
2 Scientific design and advanced processing technique
tube ice maker has scientific design and can also make the best ice making system according to customer's actual demand, with world leading ice making technology and processing and testing equipments. Each part is processed with strict technique requirement and strictly tested before using.
3 Sanitary
Quality and sanitary tube ice maker . All parts contacting with water are made of stainless steel SUSSO4 or SUS316L and PE material. Tube ice produced is sanitary without smell, meeting HACCP and PDA certificate requirement.
4 Efficient and environment friendly
With stable continuous running, SNOWKEY tube ice maker realizes the running without energy wasting. Compared with other ice making equipments, tube ice maker boasts the advantages of compact structure, small area, low production cost, high refrigeratjon effect and low energy consumption, etc.
5 Module design and simple maintenance
tube ice maker has module design for simple maintenance on site. Tube ice maker can be installed inside a standard container, very suitable for frequent moving occasion.
COMMERCIAL RANGE
Model NO Model IF1T-R4A IF3T-R4A IF5T-R4A
capacity(T/24hrs) Daily Output(ton/24hrs) 1t 3t 5t
cooling capacity kw 5.6kw 17.2kw 35kw
Total Input power kw 4.57kw 11.11kw 22.55kw
Cooling type (air cooled) Air cooling Air cooling Air cooling
Net Dimension MM 1320*900*900 1640*1200*1250 2000*1650*1360
Weight kg 450kg 600kg 960kg
SEMI-INDUSTRIAL RANGE
Model NO Model IF8T-R4W IF10T-R2W IF12T-R4W
Capacity (T/24hrs) 8t 10t 12t
cooling capacity Cooling capadity(kw) 50.8kw 75.5kw 85.1kw
Total Input power kw 33kw 45.52kw 53.5kw
Cooling Tower m³/h 33m³/h 45.52m³/h 53.5m³/h
Cooling type Water cooling Water cooling Water cooling Water cooling
Net Dimension mm 2200*1900*1650 2800*1750*1750 2200*1900*1900
Weight (kg) 1670kg 2020kg 2260kg
INDUSTRIAL RANGE
Model Model IF20T-R4W IF25T-R4W IF30T-R2W
Capacity(T/24hrs) Daily Output(ton/24hrs) 20t 25t 30t
cooling capacity(KW) kw 127.6kw 152.1kw 202kw
Total Input power (kw) General power(kw) 77kw 91.5kw 108.4kw
cooling tower water flow (m³/h) Cooling Tower(m³/h) 60m³/h 74m³/h 95m³/h
Cooling type (water cooled) Water cooling Water cooling Water cooling
Net Dimension MM 4000*2100*2200 4000*2100*2500 3400*2100*2550
Weight(kg) 4410kg 4960kg 5380kg
TUBE ICE MACHINE
Model NO IF3T-R4A IF5T-R4W IF10T-R4W IF30T-R4W
capacity(T/24hrs) Ice Output(ton/24hrs 3t 5t 10t 30t
cooling capacity Cooling capadity(kw) 19.8 30.6 63.2 227
Total Input power (kw) 11.3 16 34.1 98.5
Net Dimension (mm) 1600*1300*2200 1700*1300*2250 2600*1500*3100 2500*1900*2300
Weight(kg) Weight(kg) 1280kg 1600kg 2750kg 8430kg
Containerized FLAKE ICE PLANT
Model Model IFCT-20T IFCT-30T IFCT-40T IFCT-50T IFCT-60T IFCT-80T
Capacity) (T/24hrs 20 30 40 50 60 80
cooling capacity (kW)
....
