Screw Water Heater,screw Water Heat Pump Water Heater,commercial Heat Pump Water Heater Screw

Name: Screw Water Heater,screw Water Heat Pump Water Heater,commercial Heat Pump Water Heater Screw
Brand: YUAO
SKU: 141977330
Availability: InStock

Screw Water Heater,screw Water Heat Pump Water Heater,commercial Heat Pump Water Heater Screw thumbnail-1

Screw Water Heater,screw Water Heat Pump Water Heater,commercial Heat Pump Water Heater Screw photo-1

US$ 1 - 2,000 MOQ: 50 Sets

Key Specifications

Get Latest Price

Type:

Evacuated Tube

Pressure:

Pressurized

Circulation Type:

Direct / Open Loop (Active)

Contact Supplier Request Quote Chat Now

Shanghai Yuao Refrigerant Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Evacuated Tube

Pressure Pressurized

Circulation Type Direct / Open Loop (Active)

Heating System Thermosyphon (Passive)

Connection Type Split

Installation Wall Mounted

Housing Material Stainless Steel

Certification CB, CE, CSA, EMC, EMF, GS, LFGB, Other, SASO, UL, UR, CB, CE, CSA, EMC, EMF, GS, LFGB, RoHS, SASO, UL, UR

Capacity 18000

Place of Origin Shanghai, China

Brand Name YUAO

Model Number YACH-5000W

screw water heater,screw water heat pump water heater,commercial heat pump water heater screwwater heat pump heat recovery ,Energy saving compressor water heater,heat recovery compressor air water heat pump heat recovery ,Energy saving water heater,heat recovery compressorheating recovery water heater ,heating recovery heat pump,heat recovery water heater

solar water source heat pump ,solar water heat pump, solar heat pump,geothermal water source ,to water heat pump, water heat pump,air water heat pump,DC inverter air water heat pump, air source heat pump water heater inverter

inverter heat pump,DCinverter heat pum water heater,DCinverter heat pump water heater

solar heat pump, solar air-conditioner,air heat pump water heater,water pump solar,air-conditioner,Hybrid Solar airconditioner,cooling unit,mix solar air cooling & heat pump,solar air conditioner

YAWH Water source heat pump air condtioner (cooling water) unit (C series)
Model NO			070CC	080CC	105CC	130CC	150CC	160CC	180CC	210CC	220CC	260CC	280CC
Spec			070CC	080CC	105CC	130CC	150CC	160CC	180CC	210CC	220CC	260CC	280CC
Rated cooling capacity		Kw	226	275	354	389	469	565	607	664	717	840	938
cooling capacity input power		kW	43	53	68	74	88	105	112	123	130	149	177
heating capacity		kW	248	302	388	425	511	613	659	721	774	903	1022
heating input power		kW	57	70	89	97	116	137	148	161	171	195	232
standard dimenstion	length	mm	3200	3200	3200	3200	3200	3200	3200	3250	3250	3400	4000
	width	mm	1200	1250	1300	1300	1300	1300	1300	1350	1350	1400	1650
	hight	mm	1750	1800	1850	1850	2050	2050	2050	2100	2100	2150	2350
unit weight		kg	1450	1600	1920	2050	2270	2430	2550	2680	2790	3250	3950
runing weight		kg	1690	1860	2200	2350	2600	2790	2950	3190	3330	3850	4570

Model NO			320CC	390CC	410CC	440CC	480CC	570CC	610CC	690CC	780CC	840CC	890CC	990CC
Spec			320CC	390CC	410CC	440CC	480CC	570CC	610CC	690CC	780CC	840CC	890CC	990CC
cooling capacity		Kw	1130	1214	1328	1433	1679	1822	1992	2150	2519	2658	2865	3360
cooling capacity input power		kW	209	225	246	260	298	337	369	390	447	492	521	595
heating capacity		kW	1227	1318	1442	1549	1805	1976	2162	2323	2708	2883	3099	3611
heating input power		kW	275	296	322	342	390	444	483	513	585	644	684	781
standard dimenstion	length		4000	4950	4950	4950	5100	5400	5400	5400	5600	5500	5500	5650
	width		1700	1700	1750	1750	1800	2400	2400	2450	2450	2550	2550	2600
	hight		2400	2400	2450	2450	2500	2500	2500	2550	2550	3100	3100	3100
unit weight		kg	4550	4960	5100	5220	6150	7300	7450	7800	9250	9300	9550	11550
runing weight		kg	5300	5840	6020	6140	7100	8400	8600	9000	10550	10700	11050	13150
specification.
1.The unit water side desin as pressure 1.0MPa .
2.Nominal Cooling capacity according to water let/outlet temperature 18/29°C ,loading side water inlet/outlet12°C/7°C, Heating capacity according to water inlet 15°C loading sie standardization
Heating work conditioning use the cooling work conditioning water flow volume.
3.Nominal work conditioning,the unit 100% heating recovery , water source side water inlet teperature 15°C, life side water inlet /outlet temperature 45°C/50°C.
