Water Heat Pump,hot Water Heat Pump,integrated Heat Pump Water Heater

Water Heat Pump,hot Water Heat Pump,integrated Heat Pump Water Heater thumbnail-1
Water Heat Pump,hot Water Heat Pump,integrated Heat Pump Water Heater photo-1
US$ 1 - 2,000 MOQ: 50 Sets
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Pressurized
Circulation Type:
Direct / Open Loop (Active)
Contact Supplier Request Quote Chat Now
Shanghai Yuao Refrigerant Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Evacuated Tube
Pressure Pressurized
Circulation Type Direct / Open Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Split
Installation Wall Mounted
Housing Material Stainless Steel
Certification CB, CE, CSA, EMC, EMF, GS, LFGB, Other, SASO, UL, UR, CB, CE, CSA, EMC, EMF, GS, LFGB, RoHS, SASO, UL, UR
Capacity 18000
Place of Origin Shanghai, China
Brand Name YUAO
Model Number YACH-5000W

water heat pump,hot water heat pump,integrated heat pump water heater

water heat pump,hot water heat pump,integrated heat pump water heater heat pump water / water,water to water heat pump,heat pumps heating and waterwater to heater heat pump,river source water heater,lake source heat pumpwater heater ,water source water heater,water heat pump water heater

YASRWATER SOURCE HEATP PUMP AIR CONDTIONER (integral type F series)
Spec    model NO L008HHF L009HHF L013HHF L016HHF L019HHF L024HHF L030HHF L036HHF L043HHF L052HHF L062HHF L072HHF
rated cooling capacity    kW 2.1 2.7 3.6 4.3 5.7 6.4 8.4 9.2 10.0 12.2 15.2 17.7
Rated heating capacity  kW 2.5 3.2 4.6 5.5 6.8 7.3 9.6 11.7 12.2 14.5 18 21.1
Cooling  input power     kW 0.56 0.74 0.93 1.1 1.4 1.7 2.1 2.4 2.5 3.2 4.1 4.6
Heating input power      kW 0.55 0.8 1.1 1.2 1.6 1.8 2.2 2.6 2.7 3.1 4.0 4.9
Dimenstion    mm 815*576*380 922*597*432 1098*640*504 1347*790*534
weight       kg 58 59 60 61 70 72 102 104 105 142 144 145
circulating air volume   m3/h 450 510 650 730 1020 1200 1600 1900 2000 2400 3200 3300
Static pressure       Pa   12 15 30 30 30 30 50 50 50 80 80 80
specification
1.Parameters in the form are messured in the rated working state acording to GB/T19409-2003 standard work conditioning.
2.Cooling capacity according to air inlet temperature 27°Cdb,19°Cwb and water let/outlet temperature 30°C/35°C  standardization . Input power calculate inculding the fan power , without system pump power.
3.Heating capacity according to air inlet temperature 20°Cdb,15°Cwb and water inlet 20°C  standardization . Input power calculate inculding the fan power , without system pump power.
4.  Noise messured conditioning The distance 1 meter  test in  background noise level 24dB(A) anechoic  laboratory.
5.The  data will  keep improving the unit right ,please follow as the mark .
6. The  electric supply is  up to work conditioning needed , please contact .

...
