Pool Water Heater,swinmming Pool Heater,air Source Swimming Pool Water Heater

Pool Water Heater,swinmming Pool Heater,air Source Swimming Pool Water Heater thumbnail-1
Pool Water Heater,swinmming Pool Heater,air Source Swimming Pool Water Heater photo-1
US$ 1 - 2,000 MOQ: 50 Sets
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Pressurized
Circulation Type:
Direct / Open Loop (Active)
Contact Supplier Request Quote Chat Now
Shanghai Yuao Refrigerant Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Evacuated Tube
Pressure Pressurized
Circulation Type Direct / Open Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Split
Installation Wall Mounted
Housing Material Stainless Steel
Certification CB, CE, CSA, EMC, EMF, GS, LFGB, Other, SASO, UL, UR, CB, CE, CSA, EMC, EMF, GS, LFGB, RoHS, SASO, UL, UR
Capacity 18000
Place of Origin Shanghai, China
Brand Name YUAO
Model Number YACH-5000W

pool water heater,swinmming pool heater,air source swimming pool water heater,commercial heat pump water heater,induction hot water heater,small heat pump water heaterwater heat pump,hot water heat pump,integrated heat pump water heater heat pump water / water,water to water heat pump,heat pumps heating and waterwater to heater heat pump,river source water heater,lake source heat pumpwater heater ,water source water heater,water heat pump water heater

Technical data
Model Number YA-300R/SN2-N
PRICE    FOB SHANGHAI
Air 15°C/Water 26°C [2]
 Heating Capacity W 31500
Heating Input W 7135
Normal Current A 14.25
COP   4.41
Air 35°C/Water 27°C [3]
 Cooling Capacity W 25600
Cooling Input W 9140
Normal Current A 16.78
EER   2.80
Max. Current
 A 24
Power Cable Cross Section  MM2 3*3.5
Power Supply   380V~50Hz
Setting Temp. Range °C 15°C~40°C
Running Temp. Range °C -5°C~43°C
Water Heat Exchanger   Titanium PVC Tank
Water Inlet/Outlst Dimension   2"
Hydraulic Connection MM PVC 63
Min. Water Flow M3/H 10
Sound Pressure Level at 1M/4M/10M [4] dBA 54/42/33
Unit Dimentions(L*W*H) MM 1450*710*1170
Packing Dimentions(L*W*H) MM 1535*845*1325
Net Weight Kg 250
Refrigerant   R410A
Display   LCD
Mode   Heating/Cooling/Auto.
[2] Ambient air temperature 15°C(DB)/12°C (WB) inlet water temperature 26°C
[3] Ambient air temperature 35°C(DB)/27°C(WB), inlet water temperature 27°C
[4] Noise from 1meter,4 meters or 10 meters (in DBA) (As in the directives EN ISO 3741 & EN ISO 354...)

Air source heat pump pool heater(commercial series) is designed  for commercial pools.Such as Hotel pools, commercial pools, water park pools.

1) Base frame and external panel made of galvanized powder coated steel.

2) Dfrosting function is standard . reverse cysle valve included.

3) Flow switch is  for  water flow protection.

4) Titanium coil exchanger with full  resistance against corrosion ensure a working life  of 15 years.

5) Intelligent controller and adjustment by quik-mind microprocessor.

pool water heater,swinmming pool heater,air source swimming pool water heater

....
