Home > Products > Carbon fiber product > JX-T300-3K-P200 CARBON FIBER FABRIC
JX-T300-3K-P200 CARBON FIBER FABRIC
- 0 per Month
- China port
- T/T Credit Card
- 3K 1500D Kevlar Carbon Fiber And Aramid Woven Mixed Fabric
- 3K 240gsm Honeycomb Hexagon Carbon Fiber Fabric Cloth Materials
- 3k UD Prepreg Carbon Fiber Fabric
- High-Strength 3k 2x2 Twill Weave Carbon Fiber Fibre Prepreg Fabric
- 3K Plain Weave Carbon Fibre Fabric
- 3k 6k 12k Twill Weave Carbon Fiber Fabric Cloth Price
Product Details
Supply Type: | Make-to-Order |
Product Description
Specifications
1plain2.High structure strength
3Thread: 3k,
Product name:
Specification for the JX-CFWC
JX Product No. | Weaving Method | Carbon fiber | Warp & Weft yarn count | Size |
Weight (g/m2) | ||
Warp | Weft | Width | Thickness | ||||
JX-T300-1K-P95 | plain | 1K | 1K | 7*7 | 100 | 0.15 | 95 |
JX-T300-1K-P120 | plain | 1K | 1K | 9*9 | 100-127 | 0.16 | 120 |
JX-T300-1K-T120 | twill | 1K | 1K | 9*9 | 100-127 | 0.16 | 120 |
JX-T300-1K-T140 | twill | 1K | 1K | 10.3*10.3 | 100-150 | 0.17 | 140 |
JX-T300-1K-T150 | twill | 1K | 1K | 11*11 | 100-150 | 0.18 | 150 |
JX-T300-3K-P160 | Single track | 3K | Ec511 | 8*4 | 100-150 | 0.125 | 160 |
JX-T300-3K-P160 | plain | 3K | 3K | 4*4 | 100-150 | 0.20 | 160 |
JX-T300-3K-T160 | twill | 3K | 3K | 4*4 | 100-150 | 0.20 | 160 |
JX-T300-3K-4H185 | 4H satin weave | 3K | 3K | 4.7*4.7 | 100-150 | 0.22 | 185 |
JX-T300-3K-4H193 | 4H satin weave | 3K | 3K | 4.8*4.8 | 100-150 | 0.23 | 193 |
JX-T300-3K-T196 | twill | 3K | 3K | 4.9*4.9 | 100-150 | 0.25 | 196 |
JX-T300-3K-P196 | plain | 3K | 3K | 4.9*4.9 | 100-150 | 0.25 | 196 |
JX-T300-3K-P200 | plain | 3K | 3K | 5*5 | 100-150 | 0.25 | 200 |
JX-T300-3K-T200 | twill | 3K | 3K | 5*5 | 100-150 | 0.25 | 200 |
JX-T300-3K-P210 | plain | 3K | 3K | 5.2*5.2 | 100-150 | 0.25 | 210 |
JX-T300-3K-P220 | plain | 3K | 3K | 5.5*5.5 | 100-150 | 0.26 | 220 |
JX-T300-3K-T220 | twill | 3K | 3K | 5.5*5.5 | 100-150 | 0.25 | 220 |
JX-T300-3K-4H220 | 4H satin weave | 3K | 3K | 5.5*5.5 | 100-150 | 0.26 | 220 |
JX-T300-3K-P240 | plain | 3K | 3K | 6*6 | 100-150 | 0.33 | 240 |
JX-T300-3K-T240 | twill | 3K | 3K | 6*6 | 100-150 | 0.33 | 240 |
JX-T300-3K-P280 | plain | 3K | 3K | 7*7 | 100-150 | 0.34 | 280 |
JX-T300-3K-2T280 | 2*2 twill | 3K | 3K | 7*7 | 100-150 | 0.34 | 280 |
JX-T300-3K-4T280 | 4*4 twill | 3K | 3K | 7*7 | 100-150 | 0.34 | 280 |
JX-T300-3K-5H280 | 5H satin weave | 3K | 3K | 7*7 | 100-150 | 0.35 | 280 |
JX-T300-3K-8H320 | 8H satin weave | 3K | 3K | 8*8 | 100-150 | 0.36 | 320 |
JX-T300-3K-8H370 | 8H satin weave | 3K | 3K | 9.3*9.1 | 100-150 | 0.38 | 370 |
JX-T300-3K-6K-P280 | plain | 6K | 6K | 3.5*3.5 | 100-150 | 0.35 | 280 |
