Specifications
Stainless Steel Wire Mesh (14 years factory)1,ISO9001&14001
2,304,304L,316,316L.
3,width:30cm-5m,standard30m/60'
4,L15-100m
Stainless Steel Wire Mesh (14 years factory)
Hongsheng manufactures stainless steel wire mesh in different material, mainly are SS 304, SS 304L, SS 316, SS 316L, The mesh range from 1 mesh to 400 mesh, in different weave types, such as plain weave, twill weave, dutch weave and so on width of roll : 0.5M -- 4.3 M; length of roll: 25M -- 100M. Stainless steel wire mesh include mesh, cloth, insect screen and other products.
Packing: Water Proof Paper, wooden Crate.
Dutch plain Weave Stainless Steel Wire Mesh
woven as a plain weave. Each warp wire and each weft wire passes over and under the next adjacent complementary wire, as in normal Plain Weave, except the warp wires are larger in diameter than the weft wires. This allows a greater mesh count in the weft direction.
Characteristics: ”zero”—aperture, more solid than square or rectangular mesh, relative high open area, suitable for all kinds of filtration
The mesh in processing
The Specifications of the Stainless Steel Wire Mesh
Mesh Count
Warp x WeftWire Dia mm
Warp x WeftWire Dia inch
Warp x WeftMicron
Rating8 x 85 0.360 x 0.320 0.0140 x 0.0125 320-340 12 x 64 0.580 x 0.420 0.0230 x 0.0165 265-285 14 x 88 0.500 x 0.350 0.0200 x 0.0140 215-235 24 x 100 0.350 x 0.250 0.0140 x 0.0100 115-125 30 x 150 0.230 x 0.180 0.0090 x 0.0071 95-100 40 x 200 0.180 x 0.140 0.0070 x 0.0055 70-75 50 x 250 0.140 x 0.114 0.0055 x 0.0045 55-60 80 x 400 0.125 x 0.071 0.0050 x 0.0028 40-45
Anping Hongsheng Wire Mesh Factory
Tel:86-318-7688868
Fax:86-318-7522627
Ms Sindy Li
