Specifications
Stainless Steel Wire Mesh (14 years factory)1,ISO9001&14001
2,304,304L,316,316L.
3,width:30cm-5m,standard30m/60'
4,L15-100m
Stainless Steel Wire Mesh (14 years factory)
Hongsheng manufactures stainless steel wire mesh in different material, mainly are SS 304, SS 304L, SS 316, SS 316L, The mesh range from 1 mesh to 400 mesh, in different weave types, such as plain weave, twill weave, dutch weave and so on width of roll : 0.5M -- 4.3 M; length of roll: 25M -- 100M. Stainless steel wire mesh include mesh, cloth, insect screen and other products.
Packing: Water Proof Paper, wooden Crate.
Plain Weave Stainless Steel Wire Mesh
Each weft wire passes over one and under one warp wire, and each warp wire passes over one and under one weft wire, every weft wire have and warp wire the same diameter.
Characteristics: square aperture ,high flow through , relative high open area, as result less pressure drop during filtration suitable for all kinds of filtration up to 63 µm.
The mesh in processing
The Specifications of the Stainless Steel Wire Mesh
Anping Hongsheng Wire Mesh Factory
Tel:86-318-7688868
Fax:86-318-7522627
Ms Sindy Li
