We wholesale High efficient workshop ventilation system
Advantages:
1. Molding punch structure are taken to the manufacturing process. It is complex in manufacturing. But it is stable and no deformation. The steel consumption is half of normal heat exchanger.
2. New structure of heat exchange plate are taken. It giantly enchanced the heat transfer coeffient of the heat exchanger. Heat tranfer efficient is 2~3 times of normal tubular heat exchanger and fin tubes heat exchanger. The total file heat tranfer coefficient is higer than 45W/m2.
3. No leakage due to the whole welding structure are taken.
4.Special expansion and elastic structure are taken to meet thermal expansion and contraction. The equipment can meet high temperature of 950℃ conditions.
5. Modularization design are taken. Random combinations can be make to form large heat exchanger of 10000m2
6. Combined insulation are taken. Surface temperature of the equipment will lower than 40℃.
Application: Recover waste gas to generate hot air or hot gas
*********************************************************************************************************
If you are insteresting in our Workshop ventilation system,click here to contact with Jenny Yang.
*********************************************************************************************************
Product Model:
Model | Air volume (m3/h) | Residual pressure (Pa) |
Volts/ Hertz | Motor Power (Kw) | Summer | Winter | Noise level [dB(A)] | NET (kg) | Dimension (mm) | ||
Tempera- ture efficiency (%) | Tempera- ture efficiency (%) | ||||||||||
ERV-40W | 4000 | 220 |
380V -3 -50Hz | 1.0*2 | 116 | 75 | 59 |
| 333 | 2340×840 ×1140 | |
ERV-50W | 5000 | 220 | 1.8*2 | 118 | 75 | 60 |
| 413 | 2340×1030 ×1140 | ||
ERV-60W | 6000 | 240 | 1.8*2 | 120 | 81 | 62 |
| 488 | 2700×910 ×1360 | ||
ERV-80W | 8000 | 240 | 2.2*2 | 117 | 78 | 64 |
| 553 | 2700×1130 ×1360 | ||
ERV-100W | 10000 | 260 | 3.0*2 | 119 | 76 | 67 |
| 755 | 2700×1450 ×1460 | ||
ERV-120W | 12000 | 260 | 1.8*4 | 117 | 77 | 65 | 867 | 2700×1700 ×1360 | |||
ERV-160W | 16000 | 260 | 2.2*4 | 118 | 79 | 66 |
| 993 | 2700×2130 | ||
*********************************************************************************************************
If you are insteresting in our Workshop ventilation system,click here to contact with Jenny Yang.
*********************************************************************************************************
ventilation system:High efficient workshop ventilation system
| Brand | AIR-ERV |
Production Capacity | 10000 Piece/Pieces per Month |
| Material | Normal Aluminum,Blue coating Aluminum,Epoxy coating Aluminum,steelness foil |
| Terms | FOB XIAMEN |
| Place of Origin | China |
| Feature | ECO-friendly |
| Payment terms | 30% deposit before we make the production, 70% balance paid after we finished the order.Sample 100% T/T |
| Order delivery | 25-30days after receiving 30% deposit |
| Packing | 1pcs/polybag,50pcs/inner box,1000 or 500 pcs/out carton |
| Shipment means | by sea, by air, by express etc. |
1. AIR-ERV can supply OEM service for customers.
2. Produce ERV/HRV, heat exchanger according to customer's special demands.
3. Supply spare parts according to order quantity.
4. General testing and operational test carried out for every units before delivery.
5. Long warranty period.
*********************************************************************************************************
If you are insteresting in our Workshop ventilation system,click here to contact with Jenny Yang.
*********************************************************************************************************
Xiamen AIR-ERV Technology Co.,Ltd is a national high-tech enterprise established in 1996. Xiamen AIR-ERV is a company comprising of R & D, manufacturing, sales and service. Our skeleton members are comprised of experts who were working on heat transfer and energy recovery technology and application. Also we have a lot of experienced manufacturing worker. We are a good example of production-study-R&D. We mainly focus on the industrial system optimization (heat recovery) and environmental protection based on our continuous technology innovation.
Our company is located in a beautiful and renowned Xiamen City, Fujian Province, China. There are about 30000m2workshop for manufacturing. We have ISO9001 International Quality System certificate. We can supply heat recovery ventilation,air to air heat exchanger,ventilation system,air ventilation.The annual manufacturing capacity is more than 10,000 pcs. The annual sales amount is about USD 80, 000, 000. Our products cover industry fields such as Iron Steel, Metallurgy, Petro Chemical, Power, Coal Chemical, Carbon, Foods, Dyeing, Textile, Paper-making, Material and Transportation.
We can provide equipment or engineering service up to the clients’ option. Our vision is to be a synthetical service supplier of environmental protection and to be a respected public company. Welcome to inquire and visit our company!
AIR-ERV partner
AIR-ERV cooperate with world famous brand or offer OEM service including Media,Shenling,Daikin, etc.
Air-ERV Certificate:
Who Need HRV?
Every home (new and old) needs ventilation to bring in fresh air, to remove stale air, and provide moisture control.
Why HRV?
HRV introduces fresh air to a building and improves climate control, whilst promoting efficient energy use.
While opening a window does provide ventilation, the building's heat and humidity will then be lost in the winter and gained in the summer, both of which are undesirable for the indoor climate and for energy efficiency, since the building's HVAC systems must compensate.
Use our High efficient workshop ventilation system to bring you the most efficiency energy save.
