Specifications
1.Siemens transmitter2.Good warranty
3.Best price
Product Overview
The transmitter is based on the latest developments within digital signal processing technology – engineered for high measuring performance: Fast response to step changes in flow Fast dosing applications Entrained gas High immunity against process noise High turndown Easy to install commission and maintain FCT030 is available as standard with 4-20 mA analog output with HART 7.2. Additional input / output functions can be freely configured for analog, pulse, frequency, relay or status. The transmitter comes with user configurable graphical display and new SensorFlash® technology, a micro SD card for configuration backup, firmware update and data storage. In order to make a complete flowmeter system, the SITRANS FCT030 transmitter must be combined with the sensor SITRANS FCS400. Features Digital signal transfer (Sensor and transmitter) SensorFlash® removable micro SD card SIL3 safety integration certified at design level Modular construction Graphical display, same across PI Certified for custody transfer 100 Hz update rate to all outputs Typical applications: Chemical process industry, Oil & gas industry, Automotive industry and Power generation & utility industry.
Detail
| Architecture | Compact or remote configuration | ||
| Communication | HART 7.2 | ||
| EMC performance | EN 61326-3-2 | ||
| Material | Aluminium with corrosion-resistant coating | ||
| Enclosure rating | IP67 | ||
| Mechanical load | 18 to 1000 Hz random, 3.17 G rms, in all directions | ||
| I/O | Up to 4 channels combining analog, relay or digital outputs and binary input | ||
| Display | Full graphical display, 240 x 160 pixels | ||
| Power Supply | 24 to 90 V DC, 100 to 240 V AC | ||
| Approvals | Hazardous areas | ATEX, IECEx, FM, NEPSI, CSA, TISS, GOST | |
| Hygenic | 3A | ||
| Complying with NAMUR | |||
| OIML R 117 | |||
| Certificates | ATEX, IECEx, FM, NEPSI, CSA, TISS, GOST, PED, CRN, 3A | ||
| Compact system SITRANS FC430 | SIL 3 | ||
Benefits
- Secure, digital transfer of measurement data from the Sensor
- Highly secure operation in safety critical applications
- Easy maintenance because modules can be exchanged rapidly
- SensorFlash transfers setup and operating data
- SensorFlash provides simple sensor replacement into existing transmitter
- Non-volatile memory of all setup and operation data
