Help CenterAPI 5L Oil/Gas Carbon Steel Seamless Line Pipes
Related Products
-
Carbon Steel Line PipeUS$ 100 - 300MOQ: 10 Tons -
API 5DP Drill Pipe for Well DrillingUS$ 50 - 100MOQ: 10 Tons
-
Tricone Bits, Fast Drilling Rate, Cutting Structure DurabilityUS$ 1 - 300MOQ: 1 Piece
-
Drilling Tool, Non-magnetic Drill CollarUS$ 1 - 50MOQ: 10 Tons
-
Drill Collar With API Spec7-1 and SY5411 StandardsUS$ 1 - 50MOQ: 10 Tons
Key Specifications/Special Features:
Outer diameter: 10.3 to 762mm, 1/2 to 30 inches
Wall thickness: 1.24 to 63.5mm, SCH 5S, SCH 10S, SCH10, SCH20, SCH30, SCH40S, STD, SCH40, SCH60, SCH80S, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS and more
Length: random length, fixed length, SRL, DRL
Standards: API 5L, API 5CT, ASTM A106, ASTM A53, DIN2440, IO3183, ISO11960 and more
Quality grades: first class, prime, newly produced, secondary, stock and more
Material/steel grade: A, B, X42, X46, X52, X56, X60, X65, X70, L175, L175P, L210, L245, L290, L320, L360, L390, L415, L450, L485, BN, X42N, X46N, X52N, X56N, X60N, BM, X42M, X46M, X52M, X56M, X60M, X65M, X70M, X80M, X90M, X100M, L245R, L290R, L245N, L290N, L320N, L360N, L390N, L415N, L245M, L290M, L320M, L360M, L390M, L415M, L450M, L485M, L555M, L625M, L690M, H40, J55, K55, L80, N80 and more
End: plain end, beveled, cut square, grooved, threaded, coupling and more
Finishes: bare, varnished, zinc coating, anti-corrosion, 3PE/PP, 2PE/PP, EP/FBE and more
Packing: small sizes packed by steel strips into bundles, big sizes in loose pieces or customized
Applications:
Line pipe for use in pipeline transportation systems in the petroleum and natural gas industries
For use as casing and tubing for wells, screwed and socketed steel tubes and tubular and for plain end steel tube
Used for the conveyance of fluids as well as for other applicationsSuitable for nominal pressure 25 for liquids and nominal pressure 10 for air and non-hazardous gases
Pressure purposes
Applies to structural hollow sections
General structure purpose and pressure service and more
Seamless Steel Pipes
Product name Seamless Steel Pipe (SMLS)
Out diameter 10.3mm-762mm, 1/2”-30”
Wall Thickness
1.24mm-63.5mm, SCH 5S, SCH 10S, SCH10, SCH20, SCH30, SCH40S, STD, SCH40,
SCH60, SCH80S, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS etc.
Length Random Length, Fixed Length, SRL, DRL
Standard API 5L, API 5CT, ASTM A106, ASTM A53, DIN2440, ISO3183, ISO11960, etc.
Quality grade First class, prime, newly produced, secondary , stock etc.
Material/steel grade
A, B, X42, X46, X52, X56, X60, X65, X70, L175, L175P, L210, L245, L290, L320,
L360, L390, L415, L450, L485, BN, X42N, X46N, X52N, X56N, X60N, BM, X42M,
X46M, X52M, X56M, X60M, X65M, X70M, X80M, X90M, X100M, L245R, L290R,
L245N, L290N, L320N, L360N, L390N, L415N, L245M, L290M, L320M, L360M,
L390M, L415M, L450M, L485M, L555M, L625M, L690M, H40, J55, K55, L80, N80,
etc.
End Plain end, beveled, cut square, grooved, threaded and coupling, etc.
Finish Bare, varnished, zinc coating, anti-corrosion, 3PE/PP, 2PE/PP, EP/FBE, etc.
Packing
Small sizes packed by steel strips into bundles, big sizes in loose pieces; can be
packed as customers’ special requirements
Application
- Line pipe for use in pipeline transportation systems in the petroleum and
natural gas industries
- for use as casing and tubing for wells, screwed and socketed steel tubes and
tubular and for plain end steel tube
-used for the conveyance of fluids as well as for other applicationsContact Person: Sheila Sha
Add: Caigongzhuang Industrial Park, Jinghai County, Tianjin,China
Mail: sheila at SKYPE: sheila.zhongshun
Zhongshun Steel Pipe, Connecting the World.
- suitable for nominal pressure 25 for liquids and nominal pressure 10 for air and
non-hazardous gases
- pressure purposes
- applies to structural hollow sections
- general structure purpose and pressure service etc.
