Low Cost Magnetostrictive Liquid Level Transmitter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LGSY SeriesFloating-ball Pressure GaugeNegotiableMOQ: 1 Piece -
Good Price Huba Relative PRESSURE TRANSMITTER for Refrigeration TechnologyNegotiableMOQ: 1 Piece
-
Hand Multi-Process CalibratorNegotiableMOQ: 1 Piece
-
Low Cost Float Type Continuous Liquid Level TransmitterNegotiableMOQ: 1 Piece
-
Thermal AccessoriesNegotiableMOQ: 1 Piece
Model Number
KLLT-3
Specifications
1. Rugged 316SS Construction 2. 4-20 mA or Resistance Output 3. Immune to Changes of Density and Dielectric 4.1" Resolutio| Specific gravity: | 0.7 | Power Input type: | Dry contact SPST | Power Input: | AC220V/1A, 24 VDC/0.5A |
| Output: | SPST NO/NC | Temperature rating: | -20° to 150° | Protection Ratings: | IP65 |
| Pressure rating: | <=0.5Mpa | Probe material: | SUS304/SUS316L | Mounting: | Customized |
| Float material: | SUS304/SUS316L |
Packaging & Delivery
| Packaging Detail: | Standard export pacakge in Carton |
| Delivery Detail: | 5 days |
Specifications
1. Rugged 316SS Construction
2. 4-20 mA or Resistance Output
3. Immune to Changes of Density and Dielectric
4.1" Resolution
KDLLT Continuous liquid level sensors operate on a basic voltage divider network principle. As the float rises, a magnet in the float closes a series of reed switches in sequence which varies the tapped-off portion of the voltage divider resistor network. The KDLLT has the basic voltage divider output—the regulated DC voltage input equals the maximum voltage output.
